EMI S1H2A Specification Sheet

JOB NAME: _____________________________________ LOCATION: _______________________________________
PURCHASER: _____________________________________________________________________________________
ENGINEER: _______________________________________________________________________________________
SUBMITTED TO: _________________________________ FOR: REFERENCE [ ] APPROVAL [ ] CONSTRUCTION [ ]
SUBMITTED BY: _________________________________ DATE:____________________________________________
UNIT DESIGNATION: SCHEDULE #: _______________ MODEL #: ________________________________________
WLH
CapaCities:
Cooling .................... 11,400 Btuh
Heating (High) ........ 10,600 Btuh
Heating (Low)........... 6,200 Btuh
indoor Design temp °F DB/WB
Cooling .............................. 80/67
Heating.............................. 70/57
stanDarD Features:
evaporator – High Wall mounted:
• Universal unit mounted, infrared compatible control
package, configurable to either unit mount or optional
wall thermostat operation.
• Compatible with most standard wall mounted, 24V
thermostats
• Motorized supply louver
• Integral field condensate pump connector
• Condensate pan over flow protection
• Anti-short cycle compressor protection
• Indoor coil freeze protection
• Dry mode for humidity control (optional electric heat
required)
• Memory back up for auto re-start following power
outage
• Fan purge
WLH12 ELECTRICAL SPECIFICATIONS
115/60/1 0.64
115/60/1 0.64
208/230/60/1 0.34
208/230/60/1 0.34
Enviromaster International LLC
– – 0.64 104
.75 6.5 7.14 104
– – 0.34 197
3 13.04 13.38 197
S1H
stanDarD Features:
Condenser – Side Discharge / vertically arranged:
• R-22 refrigerant
• Factory installed Low Ambient cooling to 32°F
• Duratec compressor protection package
- Suction Accumulator
- Filter dryer
- High pressure switch (manual reset)
- Thermostatically controlled crankcase heater
- Start assist
• Coated wire coils and fan guards
• Five year compressor / one year parts warranty
Thermostatically controlled crankcase heater – This feature
energizes the crankcase heater only when needed, removes
the heater from the electrical circuit at conditions where
it's not required, saving unnecessary Watts, and increasing
overall system efficiency.
S1H ELECTRICAL SPECIFICATIONS
Model Volts/HZ/PH
S1H2A
S1H2D 208/230/60/1
HEAT PUMPS SYSTEM OPTIONS WITH WLH12/S1H2
Cooling Heating
Btuh
0.8 15
11,400
8.9 15
0.4 15
16.7 20
1
WlH12-S1H2000_101
Single-Zone Cooling / Heat Pump
Rev. A [05/08]
Outdoor Design temp °F DB/WB
Cooling .................................95/75
Heating (High) ......................47/43
Heating (Low).......................17/15
Total Min
Amps Volt
115/60/1 10 104
5.1 197
SEER HSPF SHR
Btuh
10,600 13.0 8.0 .73
Rome, New York, USA
HACR
M.C.A.
BRKR
12.2 20
6.2 15
EER COP
11.5 3.4
