EMI DWPH365 (WHP36-SHC36) Specification

Heat pump air conditioning system

Advertisement

JOB NAME: _____________________________________ LOCATION: _______________________________________
PURCHASER: _____________________________________________________________________________________
ENGINEER: _______________________________________________________________________________________
SUBMITTED TO: _________________________________ FOR: REFERENCE [ ] APPROVAL [ ] CONSTRUCTION [ ]
SUBMITTED BY: _________________________________ DATE: ___________________________________________
UNIT DESIGNATION: SCHEDULE #: _______________ MODEL #: ________________________________________
CAPACITIES:
Cooling
Heating
– High
– Low
Indoor Design Temp ºF
Cooling
Heating
Outdoor Design Temp ºF DB/WB
Cooling
Heating
– High
– Low
EER
SEER
HSPF

INDOOR UNIT:

Power Supply
Max. Fuse Size
Min. Ampacity
Max. Fuse Size
Min. Ampacity
Sound
Weight

OUTDOOR UNIT:

Power Supply
Max. Fuse Size
Min. Ampacity
Sound
Weight
REFRIGERANT PIPING:
Max. Lift
Max. Length
Liquid (OD)
Suction (OD)
STANDARD FEATURES:
• Five-Year Compressor/One-Year Parts Warranty
• I/R Unit Mount Control (w/optional hand-held control)
• Dry Mode for humidity control (when optional electric heat is ordered)
• Auto Restart following a power outage
• Anti-Short Cycle protection
• Freeze Protection
• Test Operation
• Side Discharge/Low Profi le Condenser
• Fan Purge
• Manual Reset High Pressure Switch
Enviromaster International LLC
33,000 Btu
31,000 Btu
18,200 Btu
DB/WB
80/67
70/57
95/75
47/43
17/15
10.0
10.0
6.8
208/230/1/60
15 Amps (w/o electric heat)
.70 Amps (w/o electric heat)
30 Amps (w/5kw electric heat)
27.9 Amps (w/5kw electric heat)
54 dBa
115 Lbs
208/230/1/60
30 Amps
19.8 Amps
67.2 dBa
155 Lbs
35 Ft
100 Ft
3/8 In
7/8 In
DWPH365 (WHP36-SHC36)
17 "
"
11
/
1
4
Rev. 1.1 [12/04]
"
57
1
/
2
Rome, New York, USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWPH365 (WHP36-SHC36) and is the answer not in the manual?

Questions and answers

Summary of Contents for EMI DWPH365 (WHP36-SHC36)

  • Page 1 JOB NAME: _____________________________________ LOCATION: _______________________________________ PURCHASER: _____________________________________________________________________________________ ENGINEER: _______________________________________________________________________________________ SUBMITTED TO: _________________________________ FOR: REFERENCE [ ] APPROVAL [ ] CONSTRUCTION [ ] SUBMITTED BY: _________________________________ DATE: ___________________________________________ UNIT DESIGNATION: SCHEDULE #: _______________ MODEL #: ________________________________________ CAPACITIES: Cooling Heating – High –...
  • Page 2 EMI ENGINEERING SUBMITTAL DWPH365 (WHP36-SHC36) PART ONE “GENERAL” The Heat Pump air conditioning system shall be an EMI AmericaSeries split system. The system shall consist of a High Wall mounted packaged evaporator section Model WHP36 and matching AmericaSeries outdoor unit Model SHC36.
  • Page 3 EMI heat pump and an appropriate two stage thermostat.
