4.4.4

Marvell

The Marvell 88SE6320 SAS controller allows you to configure RAID 0 and 1 set
®
on the SAS hard disk drives.
Setting the RAID item in BIOS
You must set the RAID item in the BIOS Setup before you can create a RAID set.
To do this:
1. Install two internal SAS hard disk drives to the SAS connectors labeled
SAS1/2.
2. Boot up your computer, and press <Del> during POST to enter the BIOS
setup.
In the Advanced menu, go to Onboard Devices Configuration, and enable
3.
both Marvell SAS and SAS Boot ROM.
4. Press <F10> to save the changes and exit.
Advanced
Configure Super IO Chipset
High Definition Audio
Front Panel Type
Marvell Storage Controller
Marvell Storage Boot Rom
Marvell SAS
SAS Boot ROM
Marvell LAN1
Marvell LAN2
LAN Boot ROM
Onboard 1394 Controller
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.
ASUS P6T6 WS Revolution
SAS RAID configurations
®
BIOS SETUP UTILITY
[Enabled]
[HD Audio]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Disabled]
[Enabled]
Enable or Disable
High Definition Audio
Controller
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
4-57
