P6T6 WS Revolution specifications summary

CPU
Chipset
System Bus
Memory
Expansion Slots
Multi-GPU Support
Storage
LAN
USB
xii
LGA1366 socket for Intel
Edition / Core™ i7 Processor
Supports Intel Dynamic Speed Technology
®
* Refer to www.asus.com for Intel CPU support list
Intel X58 / ICH10R
®
NVIDIA NF200
®
Up to 6.4GT/s; Intel
®
6 x DIMM, max. 12GB, DDR3 1600 (O.C.) / 1333 /
1066 MHz, non-ECC, un-buffered memory
Triple channel memory architecture
Supports Intel Extreme Memory Profile (XMP)
®
* Due to Intel spec definition, DIMMs of DDR3-1333 or
above are supported by specific CPU models only.
** Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists)
2 x PCI Express 2.0 x16 slots (at x16 or x8 mode)
1 x PCI Express 2.0 x16 slots (at x16 mode)
2 x PCI Express 2.0 x16 slots (at x8 / x8 mode)
1 x PCI Express 2.0 x16 slot (at x4 mode)
* True @ x16 3-Way SLI™ in slots 1, 3 and 5 when slots
2 and 4 are not occupied
Supports NVIDIA Native and 3-Way SLI™ Technology*
®
Supports ATI CrossFireX™ Technology, up to Quad
®
CrossFireX™
* SLI support may need BIOS update. Visit www.asus.com
for more details.
Intel ICH10R Southbridge:
®
- 6 x SATA 150/300 ports
- Intel Matrix Storage supporting SATA RAID 0,1,
®
10, and 5
Marvell 88SE6320 controller:
- 2 x SAS ports supporting SAS RAID 0, 1 and 10*
Marvell 88SE6121 controller:
- 2 x eSATA 150/300 ports (SATA On-the-Go),
supporting SATA RAID 0, 1, 10 and 5**
* A SAS expander (excluded in package) is required
while using RAID 10 on SAS ports.
** A port-multiplier (excluded in package) is required while
using RAID 5 or 10 on eSATA ports.
2 x Realtek 8111C PCIe Gigabit LAN controllers,
®
supporting teaming function
12 x USB 2.0 ports (6 ports at mid-board, 6 ports at back
panel)
(continued on the next page)
Core™ i7 Processor Extreme
®
QuickPath Interconnect
