4.4.2

Installing Serial ATA hard disks

The motherboard supports Serial ATA hard disk drives. For optimal performance,
install identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for a RAID configuration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.
4.4.3 Intel
®
This motherboard supports RAID 0, RAID 1, RAID 5, RAID 10 and Intel
Storage configurations for Serial ATA hard disks drives through the Intel
Southbridge chip.
Setting the RAID item in BIOS
You must set the RAID item in the BIOS Setup before you can create a RAID
set(s). To do this:
1. Enter the BIOS Setup during POST.
Go to the Main menu, select Storage Configuration, then press <Enter>.
2.
Select the item Configure SATA as, then press <Enter> to display the
3.
configuration options.
Select [RAID] from the Configure SATA as item options, then press <Enter>.
4.
5. Save your changes, then exit the BIOS Setup.
Refer to the system or the motherboard user guide for details on entering and
navigating through the BIOS Setup.
ASUS P6T6 WS Revolution
RAID configurations
® Matrix
® ICH10R
4-49
