Asus P5K SE EPU User Manual page 81

Some of the following items appear when you set AI Overclocking to [Manual].
CPU Ratio Control [Auto]
Configuration options: [Auto] [Manual]
The following item appears when the CPU Ratio Control item is set to
[Manual].
Ratio CMOS Setting [14]
Use the <+> and <-> keys to select the CMOS ratio values from 6 to 12.
FSB Frequency [XXX]
Displays the frequency sent by the clock generator to the system bus and PCI
bus. Use the <+> and <-> keys to adjust the FSB frequency. You can also type
the desired FSB frequency using the numeric keypad. The values range from 200
to 800. Refer to the table below for the correct Front Side Bus and CPU External
Frequency settings.
PCIE Frequency [Auto]
Allows you to set the PCI Express frequency.
Configuration options: [Auto] [100] [101]~[149] [150].
FSB/CPU External Frequency Synchronization
Front Side Bus
FSB 1600
FSB 1333
FSB 1066
FSB 800
DRAM Frequency [Auto]
Allows you to set the DDR2 operating frequency.
Configuration options: [Auto] [DDR2-667MHz] [DDR2-800MHz] [DDR2-1066MHz]
[DDR2-1200MHz]
Selecting a very high DRAM frequency may cause the system to become
unstable! If this happens, revert to the default setting.
ASUS P5K SE/EPU
CPU External Frequency
400 MHz
333 MHz
266 MHz
200 MHz
4-17
