What to do next:
• To work with another piece of hardware, go to the appropriate section.
• To complete the installation or replacement, go to "Completing the parts replacement" on page 123.

Replacing the microprocessor

Attention: Do not open your computer or attempt any repair before reading and understanding the "Important
safety information" on page 1.
This section provides instructions on how to replace the microprocessor.
CAUTION:
The heat sink and microprocessor might be very hot. Turn off the computer and wait three to five
minutes to let the computer cool before removing the computer cover.
To replace the microprocessor, do the following:
1. Turn off the computer and disconnect all power cords from electrical outlets.
2. Remove the computer cover. See "Removing the computer cover" on page 77.
3. Remove the heat sink. See "Replacing the heat sink" on page 99.
Note: Place the heat sink on its side so that the thermal grease on the bottom of it does not get in
contact with anything.
4. Lift the small handle
Figure 46. Accessing the microprocessor
102
ThinkCentre Hardware Maintenance Manual
1
and open the retainer
2
to access the microprocessor
3
.
