Daewoo KOD-135P Operating Instructions Manual

Pizza maker built-in microwaves combo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Pizza Maker Built-in Microwaves Combo
OPERATING
INSTRUCTIONS
To clean the pizza tray, use only mild, nonabrasive cleaner using a sponge or soft cloth.
Important Pizza Oven Cooking Tips:
- Prior to use Pizza Oven, the grill element must be heated for about 5minutes to remove some
odors of heating elements.
- Do not use the microwave oven or the pizza oven when empty.
- After pizza cooking the fan will run for about 4minutes to cool this oven.
- Refer to the page 10 for Pizza Oven Operation Procedure.
- Before folding the handle of the pizza tray, you must push the button of the handle.
Before operating this oven, please read these instructions completely.
KOD-135P

Advertisement

Table of Contents
loading

Related Manuals for Daewoo KOD-135P

Summary of Contents for Daewoo KOD-135P

  • Page 1 Pizza Maker Built-in Microwaves Combo KOD-135P OPERATING INSTRUCTIONS To clean the pizza tray, use only mild, nonabrasive cleaner using a sponge or soft cloth. Important Pizza Oven Cooking Tips: - Prior to use Pizza Oven, the grill element must be heated for about 5minutes to remove some odors of heating elements.

  • Page 2: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

  • Page 3: Important Safety Instructions(Microwave Oven)

    IMPORTANT SAFETY INSTRUCTIONS (Microwave Oven) READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 11.

  • Page 4: Important Safety Instructions(Pizza Oven)

    IMPORTANT SAFETY INSTRUCTIONS (PIZZA OVEN) WARNING: 1. Use extreme caution when removing pizza tray or disposing of hot grease. 2. Do not clean the oven with metal scouring pads. Pieces can break off the pad and touch electrical parts, creating a risk of electric shock. 3.

  • Page 5: Handle Controls

    HANDLE CONTROLS •When using the pizza tray, you must unfold the handle of the pizza tray and check the button of the handle rise up fully. •When not using the pizza oven, you would better fold the handle of the pizza tray. •Before folding the handle of the pizza tray, you must push the button of the handle.

  • Page 6: Earthing Instructions

    EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an IMPORTANT NOTE electrical short circuit, earthing reduces the risk of The wires in this mains lead fitted to this appliance electric shock by providing an escape wire for the are cloured in accordance with the following code.

  • Page 7: Features Diagram

    FEATURES DIAGRAM 1. Door latch-When the door is closed it will 6. Door release button-Pushing this button automatically shut off. If the door is opened stops oven operation and opens the door. while the oven is operating, the magnetron will automatically shut off. 7.

  • Page 8: Features Diagram (Continued)

    FEATURES DIAGRAM (continued) Control pads for pizza oven Control pads microwave oven 11. Time set pad-Used to set the cooking time 12. One touch Cook-Used to cook or reheat and the present time. specific quantities of food. 12. Display-Cooking time, power level, indicators 13.

  • Page 9: Operation Procedure (Microwave Oven)

    OPERATION PROCEDURE (MICROWAVE OVEN) This section includes useful information about microwave oven operation. 1. Plug power supply cord into a standard 3- pronged 15Amp, 230~240V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking.

  • Page 10: Operation Procedure (Pizza Oven)

    OPERATION PROCEDURE (PIZZA OVEN) This section includes useful information about pizza oven operation. 1. Plug power supply cord into a standard 3-pronged 15Amp, 230~240V 50Hz power output. 2. Put pizza on the pizza tray. 3. Shut the pizza tray. Make sure that it is firmly closed. The pizza tray can be opened at any time If the pizza oven does not operate, check the during operation by pulling out the handle on...

  • Page 11: Controls

    CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “:0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. 1.

  • Page 12: Auto Defrost

    AUTO DEFROST AUTO DEFROSTING lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. MEAT 1. Touch AUTO DEFROST pad The DEFROST indicator light and “2--1” is AUTO once. displayed. DEFROST 2.

  • Page 13: Cooking In Microwave

    COOKING IN MICROWAVE 1. Touch POWER LEVEL pad. The Micro indicator lights. POWER (Select the desired power The display will show what you touched. LEVEL level.) This example shows power level 5. The display will show what you touched. 2. Touch the time set pads for the cooking time. NOTE : Your oven can be programmed for 59 minutes 90 seconds.

  • Page 14: Express Cook

    EXPRESS COOK EXPRESS COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the EXPRESS COOK pad. By repeatedly touching the EXPRESS COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. 1.

  • Page 15: Auto Reheat

    AUTO REHEAT AUTO REHEAT allows you to reheat many of your favorite foods by repeatedly touching AUTO REHEAT pad. When you touch AUTO REHEAT pad once, 1. Touch AUTO REHEAT pad. AUTO 1--1 is displayed. By repeatedly touching this REHEAT pad, you can select other food category as shown in the chart below.

  • Page 16: Kids Meal

    KIDS MEAL 1. Touch KIDS MEAL pad. When you touch KIDS MEAL pad once, “4-- KIDS 1” is displayed. By repeatedly touching this MEAL pad, you can select other food category as shown in the chart below. CATEGORY FOOD WEIGHT TOUCH PAD DIRECTIONS •Pick hot dogs, place on plate.

  • Page 17: Snack Cook

    SNACK COOK 1. Touch SNACK COOK pad. When you touch SNACK COOK pad once, SNACK “6--1” is displayed. By repeatedly touching COOK this pad, you can select other food category as shown in the chart below. CATEGORY FOOD WEIGHT TOUCH PAD DIRECTIONS 6--1 Nachos...

  • Page 18: Less, More

    LESS, MORE To alter cooking time while oven is in operation, use LESS or MORE.(except for defrosting and pizza menu) Touch LESS/MORE pad to decrease/increase the cooking time in multiples of 10 seconds. The overall cooking time can be increased to a maximum of 59 minutes 50 seconds. LESS/MORE pad to decrease/increase the cooking time in multiples of 10 seconds.

  • Page 19: Using The Pizza Oven

    USING THE PIZZA OVEN The pizza indicator lights and “p--1” is 1. Touch FRESH PIZZA pad. FRESH displayed. PIZZA cf) Fresh pizza ( 9:00~15:00) 2. Touch number pads for the cooking time. 3. Touch START pad to begin cooking. Pizza oven can be programmed for 15 minutes. (max. 15:00) The pizza indicator lights and “p--2”...

  • Page 20: Care Of Your Microwave Oven

    CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm Keep the inside of the oven clean. When food sudsy water or in a dishwasher. spatters or spilled liquids adhere to oven walls, wipe with a damp cloth.

  • Page 21: Questions And Answers

    QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven * Q : Why does my oven not always cook as fast without any food in it. Is it damaged? as the microwave cooking guide says? A : Running the oven empty for a short time will not A : Check your cooking guide again, to make sure damage the oven.

  • Page 22: Before You Call For Service

    BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : * Sparking in the cavity; 1. Check that the power cord is securely plugged in. 1. Check utensils. Metal containers or dishes with 2.

  • Page 23: Cooking Instructions

    COOKING INSTRUCTIONS Utensil Guide Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry.

  • Page 24: Use Your Microwave Oven Safely

    USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety Do not operate the oven if door seals or sealing interlocks. surfaces are damaged; or if door is bent; or if hinges Do not place any object between the oven front frame are loose or broken.

  • Page 25: Microwaving Principles

    MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade sources include radar, radio, television, telecommunication links and car phones. HOW MICROWAVES COOK FOOD In a microwave oven, TRANSMISSION...

  • Page 26: Cooking Techniques

    COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and The colder the food, the longer it takes to heat up. cakes, require standing time(inside or outside of Food from a fridge takes longer to reheat than the oven) after cooking, to allow heat to finish food at room temperature.

  • Page 27: Defrosting Guide

    DEFROSTING GUIDE ▶ Do not defrost covered meat. Covering might allow ▶ When defrosted, food should be cool, but softened in cooking to take place. Always remove outer wrap and all areas. If still slightly icy, return to microwave oven tray.
  • Page 28 COOKING & REHEATING CHART Cooking chart Power Cooking Time Item Special Instruction Level Per lb./450g MEAT - Chilled meat and poultry should be removed from Beef joint-Rare P-80 6-7 min. the refrigerator at least 30 minutes before -Medium P-80 7-9 min. cooking.

  • Page 29: Cooking & Reheating Chart

    Reheating chart • Baby food particularly needs to be checked carefully before serving to prevent burns. • When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully. • If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly thawed before following the heating instructions on the packed.

  • Page 30: Vegetable Chart

    VEGETABLE CHART Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water quantity is recommended - see table. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after cooking.

  • Page 31: Recipes

    RECIPES TOMATO & ORANGE SOUP 1 oz.(25g) butter 1. Melt the in a large bowl at P-HI for 1 minute. 1 medium onion, chopped 2. Add the onion, carrot and potato and cook at P- HI for 6 minutes. stir halfway through cooking. 1 large carrot &...

  • Page 32: White Sauce

    BLUE CHEESE & CHIVE JACKETS 2 baking potatoes, 1. Prick each potato in several places. Cook at P-HI (approx.9 oz.(250g) each) for 8-10 minutes. Halve and scoop the flesh into 2 oz.(50g) butter a bowl, add the butter, cheese, chives, 4 oz.(100g) blue cheese, chopped mushrooms, salt and pepper, mix thoroughly.
  • Page 33 SCRAMBLED EGG 1 /2 oz.(15g) butter 1. Melt the butter in a bowl at P-HI for 1 minutes. 2 eggs 2. Add the eggs, milk and seasoning and mix well. 2 tbsp(30ml) milk 3. Cook at P-HI for 2 minutes, stirring every 30 salt &...
