Smart Technologies SMART Board Installation Manual page 38

The table below summarizes the function of each icon in the strip.
Press this icon...
Sleep Mode Activation
Input Source Selection
Display Mode Toggle
Panel Control Menu
If you find you no longer need the Display Control icon strip, you can easily disable and remove it
(page 30).
To configure the Display Control icon strip
1. Connect the flat-panel display to a serial port on your computer (page 21).
2. Configure the On-Screen Display Control for the flat-panel display (page 28).
3. Press the SMART Board icon in the system tray, and press Control Panel.
4. Press SMART Board Settings.
5. Select Set Up Icon Strips from the drop-down list.
6. Press Display Control Strip.
An orientation screen appears.
7. At the interactive whiteboard, press the circled A on the Display Control icon strip (see the
illustration below).
8. Press the circled B at the right edge of the Display Control icon strip.
NOTE: If you press on a point that's too far from the actual letters on the icon strip, you'll
receive an error message asking you to repeat this procedure.
To disable and remove the Display Control icon strip
1. Press the SMART Board icon in the system tray, and press Control Panel.
2. Press SMART Board Settings.
3. Select Set Up Icon Strips from the drop-down list.
4. Press Remove All Strips.
5. If you want, peel off the Display Control icon strip from the front of the interactive whiteboard.
30
A
Press this
A A
Preparing the Interactive Whiteboard for Use
To do this...
Put the flat-panel display into sleep or standby
mode
Select an input source (e.g., computer, VCR or
DVD player)
Select a screen width option
Access a menu of audio and video controls for your
flat-panel display
Press this B
B B
99-00667-00 B0
