Lightolier Lytespan 22VZ4 Specification

Page 1 of 1
Ordering Information
Catalog No.
22VZ4WH
22VZ4BK
22VZ4AL

Features

1. Housing: Stamped 24 gauge steel

Finish

All Painted finishes are baked enamel.
Lightolier is a Philips group brand
5/8"
(16mm)
4 7/16"
(113mm)
2 1/2"
(63mm)
Finish Mounting
Matte White T4 Visor
Matte Black Does not accept accessory lenses,
Metallic Aluminum filters or louvers
Lytespan
®
4 5/16"
(110mm)

Labels

UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0408
Track Lighting System
Alcyon T4 120V Wall Washer Visor
™
5 1/8"
(130mm)
13/16"
(21mm)
3 7/8"
(98mm)
Compatible with Luminaires
22WW4WH, BK, AL
83W4WH, BK, AL
23F20T4WH, BK, AL
23F20BTWH, BK, AL
Type:
22VZ4
