Lightolier FBP100FE Specification

450 L
FBP100FE
9.4"
(23.9 cm)
2.4"
(6.1 cm)
1.5"
(3.8 cm)
L
UMEN INEAR
Features
Illumination: The FBP100FE
provides 90 minutes of
emergency illumination by
utilizing existing fluorescent
lighting, and produces 350-450
lumens initial emergency light
output. The FBP100FE can be
used with most 17 to 40 W
(2'-4') T8, T10, or T12
fluorescent lamps without
integral starters, including
U-shaped, HO, VHO, circline,
energy saving, and 4-pin
compacts. It is also compatible
with most 1-, 2-, 3-, and 4-lamp
electronic, standard, energy
saving and dimming AC ballasts.
See lamp operation for specific
lamp types.
Housing: Housing is
constructed of 20 gauge steel
with a high temperature
powder coat paint finish. Slim
housing allows for wireway
channel mounting on most
lighting fixtures.
Operating Temperature
Range:
32°F (0°C) to 131°F (55°C)
FBP100FE
F
LUORESCENT
Electronics: 120/277 VAC
dual voltage input with surge
protected, solid-state charging
circuitry provides for a reliable
charging system. Charging
system is complete with AC
indicator lamp and test switch.
Electrical Specifications:
Input Power
3.5 W max.
Battery
Maintenance free, sealed nickel
cadmium battery. Supplies 90
minutes of emergency power.
Estimated service life of 10
years.
Lamp Operation 1 : Operates
2
the following lamp types :
T8 linear fluorescent
T12 linear fluorescent
T9 circline
T12 U-bent
T5 long compact fluorescent
Notes:
1) Consult factory for compatibility
and performance of product with lamp
types not listed.
2) See Table 1 for specific lamp
performance and operation.
Job Information Type:
Job Name:
Cat. No.:
Notes:
E . B
M ALLAST
Page 1 of 2
Code Compliance
UL 924 listed. NFPA 70, NFPA
101, NEC, BOCA, OSHA and
IBC illumination standards.
Suitable for use in sealed and
gasketed luminaires.
Warranty
One year full electronics
warranty. One year full battery
warranty.
