Lightolier Paraplus II PPH2G8FW2FT Specification

Page 1 of 2
Features
• Direct/indirect louver appearance with soft contoured interior.
• 8 cell flat white louver with lens overlay.
• Air return models meet UL 1598, Paragraph 9.2.2.5 requirements.
• 72.0% efficient (2 lamp T5).
• Only 5" deep.
• Same fixture fits both G and T ceiling types.
• Fits flush to face of slot grid (T) ceiling.
• Static, optional.
• Louver hinges from either side.
• End of louver gasketed to eliminate light leak.
• Built-in earthquake clips.
• Can be continuous row mounted.
• Wiring access plate standard.
• Meets NYC Code requirements.
• Construction to meet Chicago Plenum requirement is available.
Mounting Methods
Exposed T-bar
by others
1-1/2"
max.
15/16"
24"
exposed t-grid ceiling
built-in earthquake clips
air return flow
Lightolier is a Philips group brand
8 Cell White Parabolic Louver With Lens Overlay, 2 Lamp Twin Tube T5
Exposed T-bar
by others
1-7/8"
max.
Acoustical
material
by others
9/16"
24"
exposed slot t-grid ceiling
Paraplus II
Direct/Indirect 2' x 2' Recessed Fluorescent
Dimensions
Acoustical
material
by others
2-1/2"
(64mm)
louver hinges
from either side
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
For Factory Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 a Philips Group
PPH2G8FW2FT
24" (610mm)
2" x 2-1/2"
Access Plate
With 7/8" dia. K.O.
24" (610mm)
Type:
Section 5/Folio M10-34
5"
(127mm)
05/08
