Lightolier Lytecaster 2022LV Specification

Page 1 of 1
5 3/8"
2022LV/2000LV Series
Standard MR16
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
2022LV Matte White 2000LV
w/Black Baffle 2000LVR
2000LVRE1
2000LVE1
2000LVE2
2004ICV/N
2000LVNT
2000AICV
Features
1. Housing: Hydroformed aluminum, .040" thick (18 ga.).
2. Eyeball Housing: Die-formed, one piece, aluminum, .040" thick (18 ga.).
Provides 358˚horizontal rotation and 0˚ to 45˚ vertical adjustment; matte white
or polished brass finish.
3. Step Baffle: Die-cast aluminum with stepped conical surface for low
brightness; precision-fitted into eyeball housing; matte black finish.
4. Trim Flange: Die-formed, aluminum .040" thick (18 ga.). Matte white or
polished brass finish.
5. Frame-In Kit: (2000LV standard frame shown) Other frames shown on the right.
See Frame-In Kit specification sheets for more details.
Options & Accessories
Retaining Clips: 1955 - For Installing in Existing Ceiling
Lightolier is a Philips group brand
Lytecaster
5 3/8"
Low Voltage
Installation Type
Standard Non-IC
Remodeler Non-IC
Remodeler Non-IC
Electronic Low Voltage Non-IC 120V
Electronic Low Voltage Non-IC 277V
Lytening AirSeal IC
®
Low Voltage Remote Transformer
AirSeal IC
®
Recessed Downlighting
®
3 3/4" Aperture MR16 Eyeball Reflector Trim
7 1/4"
2022LV/2004ICV/N
0
5 3/8"
2022LV/2000LVNT
Remote Transformer
Low Voltage
Lamping Height
5 3/8"
5 3/8"
5 3/8"
20W-50W MR16 5 3/8"
5 3/8"
20W-37W MR16 7 1/4"
20W-42W MR16 5 3/8"
20W-35W MR16 7 5/16"
Labels
UL (Suitable for Damp Locations), I.B.E.W
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • J0911
2022LV
AirSeal Insulated Ceiling
™ ®
2022LV/2000LVR
Remodeler/Non-IC
Type:
.
