5 3/8"
(137mm)
5 13/16"
(148mm)
Ordering Information
Catalog No.
Finish
22OR8WH
Matte White
22OR8BK
Matte Black
22OR8AL
Metallic Aluminum
Features
1. Track Attachment Fitting: Locking lever for mechanical/electrical
connection
2. Brass Contact: Extends for connection to second circuit
(Advent Lytespan track only)
3. Horizontal Pivot: Wireless stem profile with 365° horizontal rotation
4. Vertical Pivot: 0-90° vertical adjustment
5. Socket: Porcelain socket, medium base, nickel-plated screw shell
6. Housing: Die cast aluminum
7. Accessory Cartridge: Included; rotate clockwise to attach;
retaining ring included
Finish
All Painted finishes are baked enamel.
Dimming
Fixture may be used on a track with a dimmer.
Consult dimmer manufacturer for correct dimmer selection.
Lytespan
1 1/16"
(27mm)
8 1/4"
(210mm)
Mounting
All Lytespan Track Systems.
Does not mount on ProSpec Track.
®
Track Lighting System
1
4 15/16"
(125mm)
7
6 7/8"
(175mm)
Lamps
PAR38 Maximum 250W
(150W max. with accessories)
Accessories
Accessory Holder:
Integral
Accessories:
Accepts two total
(1 lens + 1 louver or 2 lenses)
Lens:
AF4, ADF4. Not compatible with AF4IR
Louver:
AL4HC
Labels
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • B0205
22OR8
Alcyon
™
Open Ring PAR38
2
3
3 11/16"
(94mm)
3/16"
(5mm)
4
1 11/16"
(43mm)
5
6
3 1/16"
(78mm)
5 13/16"
(148mm)
Type:
www.lightolier.com
