3 3/8"
2084/2002P1
Standard Incandescent
Complete Fixture consists of Frame-In Kit & Reflector Trim. Select each separately.
Reflector Trim
Frame-In Kit - See Individual Frame-In Kit Specification Sheets
2084WH Gloss White
2084CD Clear Diffuse
Frame-In Kit
2002P1
2003R
2000IC
2000AIC
*
For safe operation, you must use Sylvania outdoor rated lamp.
Features
1. Reflectors: Formed aluminum, .040 minimum thickness; gloss white and
clear diffuse finish.
2. Frame-In Kit: (2002P1 standard frame shown). Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
3. Gasket: Flexible, high temperature sillicone gasket ensure sealing of
electrical components.
Accessories
Replacement gasket available. Lightolier catalog no. LFG 356
Labels
U.L. (Suitable for Wet Locations - Covered Ceiling Only).
3
5 1/8"
1
Ceiling Type
Non IC
Non IC Remodeler
IC
IC, Air Seal
Lytecaster
®
Recessed Downlighting
3 3/4" Aperture Lens Free Wet Location Trim
5 9/32"
2
2084/2000IC
Incandescent Insulated Ceiling
1" Max.
3 3/8"
2084/2003R
0
Remodeler Ring
Incandescent
Lamping
Height
50W PAR20 Outdoor Rated*
3 3/8"
50W PAR20 Outdoor Rated*
3 3/8"
50W PAR20 Outdoor Rated*
5 1/2"
50W PAR20 Outdoor Rated*
5 1/2"
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • D0906
™
Non-IC
Type:
www.lightolier.com
2084
