Lightolier Lytecaster 1100FTUESEM Specification

Lytecaster
Page 1 of 1
11 3/4"
7
1 1/8"
Complete Fixture consists of Reflector Trim & Frame-In Kit.
Frame-In Kit
Voltage Lamp
1100FTUESEM
120V 26W
and
32W
Triple
Tube
Features
1. Mounting Frame: 0.036" (#20 ga.) galvanized steel. Accommodates all
ceilings up to 1" thick; including existing or inaccessible areas. Breakout
section and anchor nails for existing ceilings. Push-in/twist-out rotoclips hold
reflector flush to ceiling.
2. Junction Box: 0.063" (#14 ga.) 4" x 3 1/2" x 2" galvanized steel. U.L. listed
for maximum of 8 No. 12 ga., 75°C through branch circuit conductors. Integral
cable clamps permit attachment of nonmetallic Romex
without the need for separate connectors.
3. Mounting Bars: 0.059" (#16 ga.) galvanized steel. 13" long bars extend to
27", rotatable and lockable, with integral T-bar tabs. Attaches to wood joist or
T-bar ceilings without need of accessories.
4. Socket Housing: Steel precisely attached to reflector by spring clip.
5. Socket: Four-pin base, molded thermoplastic. Prewired with No. 18 AWM
leads to junction box.
6. Ballast: Electronic 120V, end of lamp life protected, FCC class "B" consumer
limits, class "A" sound rating. Energy Star
3" away from fixture sides and wiring compartment and must not be placed
above fixture in a manner which will entrap heat.
7. Emergency Battery: 90 minute battery backup, complete with an LED
charging indicator light and integrated test switch.
Electrical
26W
Input Volts: 120V
Input Watts: 29
Amps: .24
Minimum starting temperature is 0°F.
Recessed Downlighting
®
6 3/4" Aperture 1 Light, 120V 26/32W Triple Tube Fluorescent Frame-In Kit
1
9"
11 5/16"
3
11 5/16"
15 3/16"
Reflector Trims — See Individual Reflector Trim Specification Sheets
Satin
Reflector Cone
Cone
1143 1112 1108
1144 1112NM 1108NM
1144CD 1113 1110
1145 1113BK 1110NM
1146 1113CD
1146CD 1113WH
1113NM
1113CDNM
1113BKNM
or Armored cable
®
qualified. Insulation must be kept
®
32W
120V
36
0.31
6 13/16" Dia. Ceiling Opening
Open Downlight
Basic
Baffles
White
1105 1171
1105WH 1170M1
1105BNM
1105NM
1176
1176WH
1179M1
1179WH
Options & Accessories
Mounting Bars:
T-Bar Anchor Clips:
Concealed Spline Ceiling Kit:
Plaster Ceiling Ring:
Extra-Thick Ceiling Mounting Ring: 1967A - up to 2" thick ceilings.
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Romex ® is a registered trademark of General Cable Industries Inc.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • D0711
1100FTUESEM
5
4
13" MIN
27" MAX
Note: Ballast is 120V only
Enclosed Wall
Cross
Diffusers Washer
Blade
1132 1121 1135
1124 1135WH
1126 1186
1128 1186WH
1134 1195
1177SH 1196
1178SH 1196CD
1190
1964 - 20" set of (2)
1956 - set of (4) for use with above bars
1965 - set of (4), 1 1/2" to 2 1/2" Mtg. Ht.
1960 - 7/8" depth for wet
plaster ceilings.
Type:
www.lightolier.com
2
6
