Lightolier Lytecaster 1103R Specification

Page 1 of 1
5
1
4
3
Complete Fixture consists of Reflector Trim & Fram In Kit. Select each separately.
Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification Sheets
Reflector Cone
1143 1112
1103R
1144 1112NM
1144CD 1113
1145 1113WH
1146 1113BK
1146CD 1113BKNM
1149 1113CD
1150 1113CDNM
1151 1113NM
1151CD
Satin Cone
1108
1108NM
1110
1110NM
Features
1. Mounting Ring: .032 (#22 ga.) galvanized steel. Accommodates existing
ceilings up to 2" thick. Attaches securely to any type of ceiling material
without tools using (3) mounting straps provided. Push-in/twist-out clips
hold reflector flush to ceiling. Includes adhesive backed aperture template.
2. Junction Box: 2 1/2" X 2 1/2" X 3 1/2" (21 cu. in.) .032 (#22 ga.) galvanized
steel. U.L.listed for 90° C supply wire. Integral cable clamps permit attach-
ment of non-metallic (#12 or #14 ga.) Romex
tional connectors. Attaches to mounting ring without tools.
3. Socket Housing: Impact extruded aluminum or galvanized steel.
4. Socket: Porcelain medium base; nickel plated screw shell. Pre-wired with
#18 ga. SF1 (300 VOLT 200° C) leads to junction box.
5. Thermal Protector: Meets NEC and U.L. requirements. Do not install
insulation within 3 inches of fixture sides or wiring compartment nor above
fixture in such a manner as to entrap heat.
Options & Accessories
Thermal Protector Replacement:
Replacement Clips (Set of 3):
Labels
UL (Suitable for Damp Locations)
Lytecaster
0
6 3/4 " Aperture
2
Top View
2003R
Open Downlight
Cross Basic
Blade White Baffles Basic
1132 1176WH 1105 1170M1
1170M1 1105BNM 1171
1171 1105NM
1105WH
1176
1179M1
1179WH
cable without tools or addi-
®
1970
1997
Recessed Downlighting
®
Incandescent Non-IC Remodeler Frame-In Kit
®
Frame-in Kit
Ceiling Opening
7 1/8"
14 9/16"
Recessed Adjustable
Line Voltage
1127 1129CL
1127NM 1129CLNM
1127BK 1129GD
1127BKNM 1129GDNM
1127CDNM 1129BK
1127CD 1129BKNM
1127BNM 1129WH
1127WH
1129
1129NM
1129BKNM
Low Voltage
1152 1161
1155 1161WH
1155WH
Eyeball
1122 1123
1122WH 1123WH
Romex is a registered trademark of General Cable Industries Inc.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • G0711
1103R
2003R
Reflector Trim
Enclosed Wall
Diffusers Washer
1121 1135
1124 1135WH
1138
1126 1185
1138NM
1128 1186
1148
1134 1186WH
1148NM
1177SH
1178SH
1190
1163
1164
1182
Type:
www.lightolier.com
Open
Wet
Location
1184WH
1184CD
