Summary of Contents for Connect Tech Xtreme/104 Opto

  • Page 1: User Manual

    Xtreme/104 Opto PC/104 Serial Communications Adapter User Manual Connect Tech Inc 42 Arrow Road Guelph, Ontario N1K 1S6 Tel: 519-836-1291 Toll: 800-426-8979 (North America only) Fax: 519-836-4878 Email: sales@connecttech.com support@connecttech.com URL: www.connecttech.com CTIM-00007, Revision 0.05, June 2005...
  • Page 2: Limited Lifetime Warranty

    Xtreme/104 Opto User’s Manual, Connect Tech Inc. Limited Lifetime Warranty Connect Tech Inc. provides a Lifetime Warranty for all Connect Tech Inc. products. Should this Revision 0.05...
  • Page 3: Certification

    Certification Xtreme/104 Opto The Xtreme/104 Opto product family is to be included into a device ultimately subject to FCC, DOC/IC, and CE certification. The customer is responsible for bringing the completed device into compliance prior to resale. Connect Tech has designed the Xtreme/104 Opto with EMI and EMC considerations such as: Ground and power planes ●...
  • Page 4: Table Of Contents

    Mode 1 (one IRQ):...11 Mode 2 (two IRQs): ...11 Mode 3 (two IRQs – Xtreme/104 Opto, 4 port model only):...11 Mode 4 (four IRQs – Xtreme/104 Opto, 4 port model only): ...11 Baud Rate Selection ...13 Software Installation ...14 Specifications ...15...
  • Page 5 Xtreme/104 Opto User’s Manual, Connect Tech Inc. List of Figures Figure 1: Xtreme/104 Opto, 2 port model... 8 Figure 2: Xtreme/104 Opto, 4 port model... 8 Figure 3: Port address selection jumper setting examples... 10 Figure 4: Interrupt (IRQ) selection jumper setting examples ... 12 Figure 5: Baud rate selection jumper setting example...
  • Page 6: Customer Support Overview

    Customer Support Overview If you experience difficulties after reading the manual and/or using the product, contact the Connect Tech reseller from which you purchased the product. In most cases the reseller can help you with product installation and difficulties. In the event that the reseller is unable to resolve your problem, our highly qualified support staff can assist you.
  • Page 7: Introduction

    NT/2000, Linux, Solaris, SCO Unix, and QNX 2, 4, and QNX 6 (Neutrino) Optical Isolation Notes The Xtreme/104 Opto uses optocouplers and isolated DC to DC converters to achieve optical isolation. The board provides 3.0 kV AC peak to peak isolation between each port and also between each port and your system.
  • Page 8: Xtreme/104 Opto Components

    10 pin connectors Pin 10 Pin 1 16C2850 UART Note: Rev A & B Xtreme/104 Opto adapters do not have positions H & I on jumper blocks, JB4, JB5, JB6, and JB7 Figure 2: Xtreme/104 Opto, 4 port model RS-232 enable/ Tx &...
  • Page 9: Hardware Installation

    SCO Unix. This can improve your system’s efficiency. The Xtreme/104 Opto offers a status port and this port is enabled and disabled using jumper F on jumper block JB3.
  • Page 10: Custom Port Addresses

    You can configure an interrupt request line (IRQ) with the jumper blocks JB1, JB2 and JB3 on the Xtreme/104 Opto adapter. Please refer to Figure 1 and Figure 2 for a description and location of the jumper blocks JB1, JB2 and JB3.
  • Page 11: Mode 1 (One Irq)

    The even ports (ports 2, 4) interrupt on one IRQ by setting jumpers on the A or C rows and the middle rows of jumper blocks JB1 or JB2. Mode 3 (two IRQs – Xtreme/104 Opto, 4 port model only): Jumper position E on the JB3 jumper block.
  • Page 12: Figure 4: Interrupt (Irq) Selection Jumper Setting Examples

    2 and 4 interrupt on IRQ 12. IRQ select Example: Mode 3 – two IRQs (Xtreme/104 Opto, 4 port model only) In the following example, Ports 1 and 2 are set to interrupt on IRQ 7 and Ports 3 and 4 interrupt on IRQ 10.
  • Page 13: Baud Rate Selection

    Baud Rate Selection The Xtreme/104 Opto is capable of baud rates up to 460.8 kbps (4X oscillator) or 115.2 kbps (1X oscillator) depending on whether a shorting block is installed across position G on the JB3 jumper block. Please refer to block JB3.
  • Page 14: Software Installation

    Xtreme/104 Opto adapters are standard multi-port serial adapters that utilize 16C2850 UARTs. In many cases, users have software that will interface directly to the Xtreme/104 Opto adapters. Many operating systems come with handlers to control access to multiple 8250 style UARTs.
  • Page 15: Specifications

    0° C to 70° C (standard version) -40° C to 85° C (extended temperature version) Humidity: 0 to 90% relative humidity, non-condensing Power Requirements Xtreme/104 Opto (2 & 4 port models) Xtreme/104 Opto User’s Manual, Connect Tech Inc. Revision 0.05...
  • Page 16: Connectors/Pinouts

    Xtreme/104 Opto User’s Manual, Connect Tech Inc. Connectors/Pinouts Table 3: P4/P5/P6/P7 - 10 pin port header pinouts Pin No. RS-232 isolated gnd. The red stripe on the CAB104 cable indicates pin 1 on the 10 pin cable header connector. Revision 0.05...
  • Page 17: Factory Default Settings

    Figure 2 Revisions A and B of the Xtreme/104 Opto adapter do not have bias resistors Revisions A & B of the Xtreme/104 Opto adapter do not have positions H & I on jumper blocks, JB4, JB5, JB6, and JB7 Xtreme/104 Opto User’s Manual, Connect Tech Inc.
  • Page 18: Rs-232/Rs-422/485 Interfaces

    Xtreme/104 Opto User’s Manual, Connect Tech Inc. RS-232/RS-422/485 Interfaces Electrical Interface Selection The Xtreme/104 Opto adapter provides jumper selectable RS-232 and RS-422/485 electrical interfaces on each port. Jumper blocks JB4, JB5, JB6 and JB7 set the electrical interfaces for the individual ports 1, 2, 3 and 4 respectively.
  • Page 19: Full Duplex Mode

    Place jumpers on positions A and C of jumper blocks JB4, JB5, JB6 and JB7 to run the individual RS-422/485 ports in half duplex mode. In this mode your Xtreme/104 Opto adapter controls the transmitter and receiver circuits. RTS is turned on prior to and during transmission to cause the transmit driver to enable and the receiver to disable.
  • Page 20: Multi-Drop 4-Wire Mode

    Jumper is on J1 Note: Rev A & B Xtreme/104 Opto adapters do not have positions H & I on jumper blocks, JB4, JB5, JB6, and JB7 J1 controls ports 1 and 2 and J2 controls ports 3 and 4. If both ports 1 and 2 are set for full duplex then J1 should not be jumpered.
  • Page 21: Line Termination

    Use jumper blocks JB4, JB5, JB6 and JB7 to terminate and bias TxD ±, RxD ±, RTS ±, and CTS ± on the individual RS-422/485 ports through jumper selectable 150 Ohm  f ixed resistors. Please note that revisions A and B of the Xtreme/104 Opto adapter do not have bias resistors (refer to KDB-284 in the Connect Tech Knowledge Database found in the Support section of our website www.connecttech.com).
  • Page 22: Figure 11: Line Bias And Termination Jumper Setting Example

    PORT 2 PORT 1 Note: Rev A & B Xtreme/104 Opto adapters do not have positions H & I on jumper blocks, JB4, JB5, JB6, and JB7 If you want to terminate half duplex RS-422/485 ports, jumper position G (Rev. A &...
  • Page 23: Rs-422/485 Cable Wiring Examples

    Notes: The RS-422/485 electrical interface consists of a differential signaling scheme. You should always connect the signals with twisted pairs. Signal reference must be connected. Xtreme/104 Opto User’s Manual, Connect Tech Inc. Xtreme/104 Opto adapter RS-485/422 peripheral TxD + RxD +...
