C-2 Compaq DAT AutoLoader Reference Guide

Temperature and Humidity Range

Power Requirements

Air-Cooling Requirement

Actions
Operating 5°C to 40°C
(∆T < 10ºC/h)
Non-Operating -40°C to 70°C
(mech.)
(∆T < 20ºC/h)
Non-Operating -40°C to 45°C
(tape)
(∆T < 20ºC/h)
NOTE: Do not cover fan. The tape drive can malfunction if the internal temperature rises
too high.
Voltage
5V +/- 5%
12V +/- 10%
Ambient temperature
Table C-2
Temperature and Humidity
Temperature
20 to 80% RH, non-condensing
Maximum wet bulb temperature = 26ºC
5 to 95% RH (∆T < 30ºC/h)
20 to 80% RH (∆T < 30ºC/h)
Table C-3
Power Requirements
Max Ripple
100 mVp-p
100 mVp-p
Table C-4
Air-cooling Requirements
< 40ºC
Humidity
Current
Typical Maximum
1.55A 2.5A
0.35A 1.2A
