4-16 Compaq DAT AutoLoader Reference Guide

LCD Menu Screens

To enter the menu mode, press and hold the select button for 5 seconds. The
AutoLoader will exit the menu mode if no button is pressed within a 5-second
period.
Menu Screen
>Version
The main menu screen. Pressing the Select button advances the arrow
to the next item on the menu: Prdrives.
Auto Load
Unload
Pressing the Enter button selects that sub menu.
Contrast
Orientation
Language
TSL10000 The version screen displays information about the autoloader including
SCSI ID#5 autoloader and drive serial numbers.
Ver.0000
S/NLxxxxxxxx
S/NDxxxxxxxx
Auto Load The auto load screen allows the auto load feature to be turned on or off.
Pressing the Select button moves the arrow to the other mode. Pressing
>OFF
the Enter button selects that mode. When auto load is ON and the
ON AutoLoader is in the one cassette mode, the AutoLoader automatically
loads the cassette into the drive.
Unload The Unload Continuous OFF selection only affects the AutoLoader when:
Continuous 1) the AutoLoader is loaded with 8 cassettes, in the 8 cassette mode, 2)
cassette #8 is in the drive and 3) a SCSI unload command is issued. The
>OFF Autoloader will unload cassette #8 and stop.
If Unload Continuous is ON, the AutoLoader will unload cassette #8 and
ON
then load cassette #1 into the drive. Pressing the SELECT button moves
the arrow to the next item on the menu. Pressing the ENTER button
selects that mode.
Contrast The contrast adjustment screen allows the display's contrast to be
Adjustment adjusted. Pressing the Select button increases contrast until maximum
contrast is reached. Pressing Select again changes the display to
minimum contrast. The number of darkened bars (see Figure 4-10,
Cassettes position) on the bottom indicates the relative magnitude of the
contrast.
Table 4-2
LCD Menu Screens
Features
continued
