Lightolier Lytecaster 1910CKU Specification

Page 1 of 2
4
3.44
Please refer to second page for trim compatibility.
Features
1. Junction Box: 2" x 4" x 3-½" (22cu.in) .032" (#22ga.) galvanized steel.
2. UniFrame™ Mounting System: Tool free mounting attaches securely to
1002P1-1102P1. (.036" (#20ga.)) Galvanized Steel adjustable speed clamp
for positive mounting to frames.
3. Ballast: 120V UL Listed Electronic Ballast, end of lamp life protection,
Class "P" thermally protected, class "A" sound rating.
4. Socket: Four-pin base, molded thermoplastic socket,
prewired with No. 18 AWM leads to ballast.
5. Socket Housing: .036" (#20ga.) Galvanized Steel housing attaches to
reflector trim by spring clip for precise optic alignment.
6. Adaptor Assembly: Male Adapting Screw is tool free and makes converting
to Compact Fluorescent as easy as changing an incandescent lamp. Clip
Socket Bracket to existing deep drawn socket cup.
Lightolier is a Philips group brand
Lytecaster Conversion Kit
1002P1 - 1102P1 Retrofit Kit, 1 Lamp, CFL, 120V Elec.
5
6
3
2
1
2.00
10" Flexible
Conduit/Greenfield
Labels
UL Listed. Suitable for Damp Location.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A1008
1910CKU
22" Flexible
Conduit/Greenfield
4.00
Type:
