Track lighting system

Advertisement

Page 1 of 2
9
8
Catalog No.
8110WH
8110BK
8110AL

Features

1. Track Attachment Fitting: Molded polycarbonate, rotates into track.
2. Push Tab: Molded polycarbonate. Locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Movable Contact: Solid brass. Extends for connection to 2nd circuit in
Advent track.
5. Ballast Housing: Extruded aluminum housing with die-cast aluminum
end caps.
6. Ballast: High Power Factor metal halide electronic ballast. Thermally
protected, 0.40A maximum input current, 45W input power.
7. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical
rotation with tensioned mounts for controlled aim.
8. Lamp Housing: Die-cast aluminum with cool-grip
temperature silicone rubber which allows aiming adjustments while fixture is
on. Integral color.
9. Lampholder: 5kV (600V) pulse rated glazed porcelain body socket with
plated nickel screw shell and lamp contacts; 18AWG SEW-2 leads encased in
fiberglass sleeving.

Accessories

Holder: 8473, holds one accessory
Diffusion/ Special Filters: AF3 series
Color Filters: ADF3 series
Louver (Hex Cell): AL3HC
Lightolier is a Philips group brand
4
1
6.75"
(172mm)
7
6.25"
(159mm)
Bottom View

Finish

White
Black
Aluminum
insulation band; a high
®
Lytespan
Track Lighting System
®
5.88"
(149mm)
Lamp
39W PAR30 CMH (M130) E26 base
Not Included

Mounting

All Monopoint, Multipoint, recessed track, suspension track, suspension
stems, sloped ceiling adapter, Basic, Advent and radius track systems only.
Ceiling and horizontal or vertical wall mounted. Not compatible with ProSpec
track system.
Finish
All painted finishes are baked powder or enamel.

Markings

cCSAus Certified for dry locations only.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0109
Step Spot Mini HID 39W PAR30 CMH
2
3
5
6
4.63"
(117mm)
Type:
8110
