Lightolier Lytecaster 2011 Specification

Page 1 of 2
5 1/2"
2011/2002P1
Standard Incandescent
7 1/4"
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit Install Type
2011 Matte White 2002P1
Faceplate
2003R
* 60W A19 with 2003R
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); matte white trim flange.
2. Pinhole: Die formed aluminum, .040" thick (18 ga.). Aperture plate and inner
shield, matte black inside, matte white finish outside. Cuts off glare at normal
viewing angles.
3. Frame-In Kit: (2002P1 standard frame shown) Other frames shown on the right.
See Frame-In Kit specification sheet for more detail.
Options & Accessories
Retaining Clips:
Lightolier is a Philips group brand
4 1/2"
2011/2004ICV/N
™ AirSeal ® Insulated Ceiling
Line Voltage
Lamping
Non-IC 40W A19
45W PAR16
50W R20, PAR20
Non-IC 40W A19
Remodeler 50W R20, PAR20
60W PAR16
1955 - For Installing in Existing Ceiling
Lytecaster Recessed Downlighting
®
3 3/4" Aperture Pin Hole Reflector Trim
5 1/2"
5 3/8"
5 3/8"
Height Frame-In Kit Installation Type
5 1/2" 2000LV Standard Non-IC
2000LVR
Remodeler Non-IC
2000LVE1 Electronic Low Voltage Non-IC 120V
5 1/2" 2000LVE2 Electronic Low Voltage Non-IC 277V
2004ICV/N Lytening AirSeal
2000LVNT Low Voltage Remote Transformer
2000AICV
Lytening AirSeal
Labels
UL (Suitable for Damp Locations), I.B.E.W
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • F1008
2011/2003R
NON-IC Remodeler Ring
™
2011/2000LV/2000LVRE1
Standard Low Voltage
2011/2000LVNT
Low Voltage Remote Transformer
Low Voltage
Lamping
20W-50W MR16
IC 20W-37W MR16
®
20W-42W MR16
20W-35W MR16
IC
®
Type:
2011
Height
5 3/8"
5 3/8"
5 3/8"
5 3/8"
7 1/4"
5 3/8"
7 5/16"
