Lightolier MJ3 series Specification

MJ3125LH12W
25.38"
(64.5 cm)
23.75"
(60.3 cm)
4.75"
(12.0 cm)
4.25"
(10.8 cm)
6.75"
(17.1 cm)
7.0"
(17.8 cm)
Features
Illumination: High-output
incandescent lamps maximize
illumination characteristics
through a specially designed
reflector and glass lens
assembly that provides glare-
free light distribution.
Housing: Heavy duty
steel cabinet is finished in
white baked-on powder
paint providing scratch and
corrosion resistance. All
metal lamp housing and swivel
assemblies in neutral cream
color to match unit housing.
Lamp heads are fully adjustable
and feature lockable swivels.
C S
HICAGO TEEL
Battery: Maintenance-free,
sealed, lead calcium battery
has an estimated service life
of 5 years, and an operating
temperature range of
65°F (19°C) to 85°F (30°C).
Nickel cadmium batteries are
optional.
Electronics: 120/277 VAC
dual voltage input with surge-
protected, solid-state circuitry.
Fully automatic, temperature
compensating, variable rate
float charging system is
complete with low voltage
disconnect, AC lockout,
brownout protection, AC
indicator lamp and test switch.
Job Information
Job Name:
Cat. No.:
Notes:
MJ3 Series
T
ROFFER
Code Compliance
All models are UL 924 listed
and meet NFPA 101 Life Safety
Code, NEC, OSHA and City of
Chicago codes.
Warranty
Three year unit warranty
(excludes lamps). One year full
plus four year prorated battery
warranty (lead calcium). Five
year full plus five year prorated
battery warranty (nickel
cadmium).
Type:
U
NIT
Page 1 of 2
