Lightolier Lytespan 8655 Specification

Page 1 of 2
Ordering Information
Catalog No. Finishes
8655 WH Matte White
8655 BK Matte Black
Features
1. Lamp Bracket: stamped steel with insulated end knob made of high tem-
perature silicone rubber which allows for aiming adjustments while fixture
is on.
2. Socket: bi-pin base ceramic socket wired with 18 ga. stranded Teflon leads
with fiberglass outer sleeve.
3. Male Jack Connector: mounted in 3/8" dia. stainless steel stem. Plugs
into any 8600 Power Jack or Extender Stem. Allows for 360° horizontal
rotation.
4. Tension Pivot Mount: die-cast aluminum. Allows for 180° vertical rotation.
5. Lamp Guard: tempered glass; can be substituted with 2" filter.
6. Spring: steel springs hold lamp and housing in place.
Mountings
All Power Jacks
Note:for wall mounting, additional bushing required
(Item No. 58622).
Lytespan
Lamps
MR16 Bi-Pin
50W Max.
Finish
All painted finishes are powder coated baked enamel.
Options & Accessories
2" UV Filter AF2UV
Electrical/Dimming
For dimming information refer to Power Jack specification sheets.
Labels
UL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • C0507
Track Lighting
®
Focal Jack Shallow Ring MR16
Type:
www.lightolier.com
8655
