Lightolier Lytecaster 1084 Specification

Page 1 of 1
1
5 1/2"
3 7/8"
6 3/16"
1084/1002P1
Standard Incandescent
Complete Fixture consists of Frame-In Kit & Reflector Trim. Select each separately.
Reflector Trim Frame-In Kit - See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1084WH Gloss White 1002P1
1084CD Clear Diffuse 1003R
1000IC
1000AICM
1004ICX
*
For safe operation, you must use Sylvania outdoor rated lamp.
† (Use Socket Extender Accessory with Short Neck)
Features
1. Reflectors: Formed aluminum, .040 minimum thickness; gloss white and
clear diffuse finish.
2. Frame-In Kit: (1002P1 standard frame shown). Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
3. Gasket: Flexible, high temperature sillicone gasket ensure sealing of
electrical components.
Accessories
LFG 356 - Replacement Gasket
Medium Base Par 30 Socket Extender
1968-For use with Short Neck PAR30 Lamps
Labels
U.L. (Suitable for Wet Locations - Covered Ceiling Only)
Lytecaster
2
3
1 1/4" Max.
Incandescent
Ceiling Type Lamping
Non IC 75W PAR30L Outdoor Rated* †
Non IC Remodeler 75W PAR30L Outdoor Rated* †
IC 60W PAR30 Outdoor Rated*
AirSeal ® IC 60W PAR30 Outdoor Rated*
AirSeal ® IC 60W PAR30 Outdoor Rated*
NEC ® is a registered trademark of the National Fire Protection Association.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • H0711
Recessed Downlighting
®
5" Aperture Lens Free Wet Location Trim
7 5/16"
1084/1000 IC Series
Incandescent Insulated Ceiling
5 1/2"
1084/1003R
0 ™
Non-IC
Remodeler
Height
5 1/2"
5 1/2"
7 5/16"
7 5/16"
7 1/4"
Type:
a Genlyte company
1084
www.lightolier.com
