Lightolier VPA1G12PR132 Specification

Page 1 of 2
Features
• Meets IES RP1 for lighting VDT areas with intense use.
• 72.0% efficient (T8).
• 1.6 spacing mounting ratio.
• Specular, low iridescence, pre-anodized aluminum louver.
• Vertical grain on louver eliminates reflected lamp image on cross
baffle.
• Louver frame with positive light stop.
• Spring loaded latches (self centering).
• Reversible louver hinging.
• Louver has protective dust guard.
• Only 6-5/8" deep body.
• Black housing exterior for cooler ballast operating temperature.
• Turned-in edges for safe handling.
• Built-in earthquake clip.
• UL-Listed twin knockout access plate.
• Air closure strips (optional).
• Construction to meet NYC Code or Chicago Plenum is available.
MOUNTING METHODS
exposed T-grid ceiling.
G
1/4" max.
1-1/2" max.
Acoustical
material
by others
15/16" or 1"
12"
Exposed T-bar
by others
plaster ceiling/flanged.
F
1-1/8" min
Plaster 3-3/4" max.
Opening
Plaster frame
must be
12-1/8"
ordered
separately
Plaster
by others
13/16"
Aluminum
12-11/16"
flange trim
earthquake clip
before
installation
1'x4' RECESSED FLUORESCENT, 3" DEEP, 12 CELL (1 ROW) PARABOLIC LOUVER
STATIC OR AIR SUPPLY/RETURN, IES RP1 FOR INTENSE VDT USE (PREFERRED)
exposed slot T-grid ceiling.
T
Exposed slot
T-bar by others
1-1/2" max.
Acoustical
material
by others
9/16"
12"
direct concealed two directional
T
T-grid ceiling.
1/4" max.
1-7/8"
max.
Acoustical
material
3/8" by others
12"
earthquake clip
installed
VP PARABOLIC
DIMENSIONS
6-1/2"
(165mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
VPA1G12PR132
Semi-specular
aluminum
12"
(305mm)
Type:
www.lightolier.com
SECTION 2/Folio G05-10 REV. A
