Lightolier Lytecaster 1178T Specification

Page 1 of 2
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
ReflectorTrim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1102T1
1178T 1102TH1
Dropped Diffuser 1102TH2
1102TM1
1102TM2
1102TH1R
1102T13U
1102T18U
1102T26U
Features
1. Reflector: Hydroformed aluminum, 18 ga.; white gloss finish on inside and
trim flange.
2. Diffuser: Translucent white polycarbonate Lexan
twist-lock action, no tools required. Gasketed to keep out dirt and moisture.
(Lexan is a registered trademark of General Electric Corp.)
®
3. Frame-In Kit: (1102T1 standard frame shown; other frames listed above.)
See Frame-In Kit specification sheet for more details.
Options & Accessories
Accessory Cones: 1550 - Matte Black Step Baffle
1550 - CL, GD, BK, BA,
Retaining Clips: 1955 - For installing in existing
Extra Wide Flange Trim Ring: 1954 - 8-7/8" O.D.
Plaster Ring: 1961
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • G0711
Lytecaster
6 3/4" Aperture Low Profile Dropped Diffuser Reflector Trim
Installation Type Lamping
Non-IC 2 Lamp 13W Twin Tube
Non-IC Compact Fluorescent
Non-IC (Gx23) 2 Pin Base
Non-IC Emergency
Non-IC Emergency
Non-IC Remodeler
Non-IC 2 Lamp 13W Quad Tube
Compact Fluorescent
(G24q-1) 4 Pin Base
Non-IC 2 Lamp 18W Quad Tube
Compact Fluorescent
(G24q-2) 4 Pin Base
Non-IC 2 Lamp 26W Quad Tube
Compact Fluorescent
(G24q-3) 4 Pin Base
. Installs and removes with
®
BG, WH, CD
ceiling.
Recessed Downlighting
®
1178T/1102T Series
Fluorescent
Height
3 7/8"
3 7/8"
3 7/8"
3 7/8"
3 7/8"
3 7/8"
3 7/8"
3 7/8"
3 7/8"
Labels
UL (Suitable for Wet Locations in Ceilings, Walls, Spas, and Hot Tubs), I.B.E.W.
Lexan is a registered trademark of General Electric.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
1178T
Type:
