PN 51480:A0
ECN 01-082
Annunciator Control Modules
ACM-16ATF
ACM-32AF
Instruction Manual
Document 51480
A
02/02/2001 Rev:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACM-16ATF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fire-Lite ACM-16ATF

Summary of Contents for Fire-Lite ACM-16ATF

  • Page 1 PN 51480:A0 ECN 01-082 Annunciator Control Modules ACM-16ATF ACM-32AF Instruction Manual Document 51480 02/02/2001 Rev:...

  • Page 2: Fire Alarm System Limitations

    While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, alarm only when heat on their sensors increases at a audible warning devices, and a fire alarm control with predetermined rate or reaches a predetermined level.

  • Page 3: Installation Precautions

    Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected sources of power before servicing.
  • Page 4 This page intentionally left blank ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 5: Table Of Contents

    Table of Contents Table of Contents 1. Product Overview General....................9 Canadian Information................ 10 Related Documentation ..............10 2. Inventory ACM-16ATF Series ................11 Control Modules................11 ACM-16ATF ................11 ACM-16ATCS4F (for use in Canada) ......... 11 ACM-16ATYF................11 Expander Modules................12 AEM-16ATF................
  • Page 6 Table of Contents 4. Installation Mounting the Backbox or Cabinet ........... 23 Wiring and Connecting..............23 Connect Wiring to Backbox or Cabinet........... 24 When the EIA-485 shield is not in conduit: ........ 24 When the EIA-485 shield is in conduit: ........24 EIA-485 Circuit ................
  • Page 7 Table of Contents Appendix B: Sensiscan 2000 Capabilities..................47 Circuits: .................... 47 System Controls: ................47 Configuring for the Sensiscan 2000........... 47 Connecting the EIA-485 Circuit............48 Providing Power to Annunciators............. 49 Installing Modules in the System............50 Program Mapping ................51 Appendix C: MS-9200 Capabilities..................
  • Page 8 This Page Intentionally Left Blank ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 9: Product Overview

    1. Product Overview This manual provides instructions for connecting an ACM-16ATF series and ACM-32AF series annunciators to various Fire Alarm Control Panels. Each appendix contains instructions that are unique to a particular FACP. General This series provides Fire•Lite FACPs with up to 32 remote serially connected annunciators, each with a capacity of 64 points, for a total capacity of 2048 points.

  • Page 10: Canadian Information

    1. Product Overview Canadian Information Canadian Information The National Standard of Canada (CAN/ULC-S527) requires that a dedicated display employ yellow visual indicators to indicate the status of supervisory inputs. The Fire•Lite annunciators listed in this manual are intended to be used for Canadian Supervisory Service in conjunction with Fire•Lite Sensiscan 200, Sensicsan 2000, MS-9200 and MS-9600 control units.

  • Page 11: Inventory

    2. Inventory ACM-16ATF Series Control Modules ACM-16ATF Incorporates 16 red “point active” and 16 yellow “trouble” LEDs, 16 momentary touch-pad switches for controlling each point, a system trouble LED, an On-line/Power LED, and a local piezo sounder with silence/acknowledge switch audible indication of alarm and trouble conditions at each annunciator.

  • Page 12: Expander Modules

    2. Inventory ACM-16ATF Series Expander Modules AEM-16ATF Expands the ACM-16ATF Series by 16 system points. The unit is identical in size and in frontal appearance to the control module. One to three of these expander modules can be supported by a control module to a maximum of 64 system points.

  • Page 13: Acm-32Af Series

    ACM-32AF Series 2. Inventory ACM-32AF Series Control Modules ACM-32AF This control module contains 32 red “point active” LEDs, a system “trouble” LED, an On-line/Power LED, and a local piezo sounder with a silence/acknowledge switch for audible indication of alarm and trouble conditions at each annunciator. Height = 8-3/8"...

  • Page 14: Cabinet & Panel Hardware

    2. Inventory Cabinet & Panel Hardware Cabinet & Panel Hardware Surface-Mount Backboxes ABS-1F This surface mounted backbox provides for the remote mounting of a single ACM-16ATF Series or ACM- 32AF Series annunciator in a surface-mount enclosure. Knockouts are provided for use with 1/2" conduit. The annunciator mounts directly to the box without a dress plate.

  • Page 15: Flush-Mount Backboxes

    Cabinet & Panel Hardware 2. Inventory Flush-mount Backboxes ABF-1F This flush mounted backbox provides for the remote mounting of a single annunciator module in a flush-mount enclosure. Knockouts are provided for use with 1/2" conduit. Includes a trim plate, mounting hardware, and an adhesive-backed annunciator label for the dress plate (15824).

  • Page 16: Semi Flush-Mount Backboxes

    2. Inventory Cabinet & Panel Hardware Semi Flush-mount Backboxes ABF-1DF This backbox mounts one Annunciator module and includes an attractive smoked glass door with keylock. Box dimensions - Height = 9-15/16" (25.24 cm) Width = 4-5/8" (11.75 cm) depth = 2-1/2" (6.35 cm). Door dimensions - Height = 10.713"...

  • Page 17: Additional Hardware

    Cabinet & Panel Hardware 2. Inventory Additional Hardware ABM-1 The Annunciator Blank Module is a two-sided dress plate identical in appearance to the front panel of the ACM-16ATF module on one side, and the front panel of the ACM-32AF module on the other side. The blank module covers unused module positions in the annunciator backbox or dress panel.
  • Page 18 2. Inventory Cabinet & Panel Hardware NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 19: Design Considerations

    3. Design Considerations Limits The standard Fire•Lite EIA-485 circuit can drive up to 32 annunciators or expanders. The number of annunciators that can engage in two-way communication is dependent on the number of addresses available with a given fire alarm control panel. The actual number of annunciator/expander modules that can be powered in a particular system depends on the current available from the control panel’s power supply.

  • Page 20: Receive Only And Transmit/Receive

    3. Design Considerations Receive Only and Transmit/Receive Receive Only and Transmit/Receive For redundant annunciation of system points, annunciators can be configured as “Receive Only” annunciators. Receive Only annunciators must be set to the same address as the annunciators they duplicate. Receive Only annunciators intercept information being transmitted to a “Receive/Transmit”...

  • Page 21: Electrical Ratings

    Electrical Ratings 3. Design Considerations Electrical Ratings Input Voltage: 24 VDC (must be filtered and power-limited). Current Draw from 24 VDC Input: Standby Alarm ACM-16ATF & ACM-32AF Series 0.040 amps 0.056 amps AEM-16ATF & AEM-32AF Series 0.002 amps 0.018 amps Data Communications Port: EIA-485 operating at 20 Kbps (must be power- limited).
  • Page 22 3. Design Considerations Annunciator Power Requirements NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 23: Installation

    4. Installation This section provides detailed instructions for installing and wiring annunciator modules and expander modules. Note: For wiring & programming details that are unique to a specific fire alarm control panel, refer to that panel's appendix in this manual, and to the panel's Instruction Manual.

  • Page 24: Connect Wiring To Backbox Or Cabinet

    4. Installation Wiring and Connecting Connect Wiring to Backbox or Cabinet Pull all annunciator wiring into the enclosure and terminate as stated and illustrated below: When the EIA-485 shield is not in conduit: • Terminate the shield at the outside of the FACP backbox (ground). •...

  • Page 25: Eia-485 Circuit

    Wiring and Connecting 4. Installation EIA-485 Circuit Connect the EIA-485 annunciator circuit wiring to the removable terminal blocks as illustrated below. • Do not “T-Tap” the power-limited EIA-485 circuit. It will not function properly. • Leave the 120-ohm ELR (PN 71244) installed across the EIA-485 ‘Out’...

  • Page 26: 24 Vdc Circuit

    4. Installation Wiring and Connecting 24 VDC Circuit CAUTION: Power must be turned off when connecting the 24 VDC power to the annunciator to avoid damaging the equipment. Connect the 24 VDC annunciator wiring to the removable terminal blocks as illustrated below: •...

  • Page 27: Installing Labels

    Installing Labels 4. Installation Installing Labels Remove the center pages of this manual. If using the custom user display labels, type the appropriate information on the labels. Carefully cut out the labels and insert them into the annunciator or expander by slipping them into the label slots on the back side of the annunciator face plate.

  • Page 28: Setting Rotary And Dip Switches

    4. Installation Setting Rotary and DIP Switches Setting Rotary and DIP Switches The Annunciator Address Rotory Switches and the DIP Switches must be set before the annunciator will operate properly. The rotory switches are set to the addresss of the annunciator. The DIP switches are set to determine how the annunciator operates.

  • Page 29: Mounting Annunciators And Expanders

    Mounting Annunciators and Expanders 4. Installation Mounting Annunciators and Expanders Set the address Rotory Switches and DIP Switches as outlined in "Setting Rotary and DIP Switches" on page 28 and the Appendix for specific fire alarm control panels. Install labels in annunciator module and expander module(s) as detailed in "Installing Labels"...

  • Page 30: Abf-2F And Abf-4F Backboxes Only

    4. Installation Mounting Annunciators and Expanders 3. If employing an AKS-1F Key Switch, mount it to the trim plate. Plug the switch leads to connector J4 on the annunciator. Connector AKS-1F Key Switch Figure 11 Annunciator Key Switch 4. Plug terminal blocks on circuit wiring in backbox to connectors on annunciator.

  • Page 31: Semi-Flush Mount Backbox (Abf-1Df/-2Df)

    Wiring the Expander Connections 4. Installation Semi-Flush Mount Backbox (ABF-1DF/-2DF) Annunciators and expanders are mounted in these backboxes the same way as they are mounted in the flush mounted type, except for the addition of the following: Aligning the door with the trim plate, slide it down onto the pins of the trim plate.

  • Page 32: Four Position Backbox (-4 Series) Or Cabinet

    4. Installation Wiring the Expander Connections Four Position Backbox (-4 Series) or Cabinet ACM-16 Series/AEM-16ATF If installing one ACM-16 Series annunciator with three AEM-16ATF expanders on the same trim plate or dress panel, perform the following steps: • Plug one end of an Expander Ribbon Cable into connector J2 on the annunciator module.

  • Page 33: Supervising Devices

    Supervising Devices 4. Installation Supervising Devices The normally closed Trouble Input can be used for supervising local power sources or other devices. If employed, all changes in status (to and from the trouble state) will be sent to the control panel in the event of device failure or restoral.
  • Page 34 Remove Center Pages for Slide-In Labels ACM-16ATF & AEM-16ATF Labels Two labels are required for the ACM-16ATF or the AEM-16ATF, one for the left side and one for the right side of each module. Each label has a distinctive format. See "Installing Labels" on page 27 for more information on these labels.
  • Page 35 Remove Center Pages for Slide-In Labels ACM-32AF & AEM-32AF Labels Two labels are required for the ACM-32AF or the AEM-32AF, one for the left side and one for the right side of each module. Each label has a distinctive format. See "Installing Labels" on page 27 for more information on these labels.
  • Page 36 NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 37: Led And Switch Functions

    5. LED and Switch Functions ACM-16ATF The following is a description of the various LEDs and switches located on the ACM-16ATF. Local Silence/Acknowledge Switch On-Line LED System Trouble LED Point-Active LED Trouble LED Control Switch Figure 14 ACM Series LED & Switch Locations Local Silence/Acknowledge Switch - This switch performs multiple functions: •...
  • Page 38 5. LED and Switch Functions ACM-16ATF System Trouble LED - Glows yellow for all trouble conditions in the system, including points or zones not mapped to the annunciator/expanders. Point-Active LED - Flashes to indicate an active point; after being acknowledged it glows until reset. Note: LED color varies by model number;...

  • Page 39: Aem-16Atf

    AEM-16ATF 5. LED and Switch Functions AEM-16ATF The following is a description of the various LEDs and switches located on the AEM-16ATF. Lamp Test Switch Inactive LEDs Point-Active LED Trouble LED Control Switch Figure 15 AEM-16ATF Series LED & Switch Locations Lamp Test Switch - When pressed, it lights all the LEDs (except the On- line LED) on the expander and sounds the piezo for as long as the switch is held down.

  • Page 40: Acm-32Af

    5. LED and Switch Functions ACM-32AF ACM-32AF The following is a description of the LEDs and the switch located on the ACM-32AF. Local Silence/Acknowledge Switch On-Line LED System Trouble LED Point-Active LED Figure 16 ACM-32AF LED & Switch Locations Local Silence/Acknowledge Switch - This switch performs multiple functions: •...

  • Page 41: Aem-32Af

    AEM-32AF 5. LED and Switch Functions AEM-32AF The following is a description of the LEDs and the switch located on the AEM-32AF. Lamp Test Switch Inactive LED Point-Active LED Figure 17 AEM-32AF LED & Switch Locations Lamp Test Switch - When pressed, it lights all the LEDs (except the On- line LED) on the expander module and sounds the piezo for as long as the switch is held down.
  • Page 42 5. LED and Switch Functions UDACT-F and Annunciators NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 43: Appendix A: Sensiscan 200

    Appendix A: Sensiscan 200 Capabilities When installed with a Sensiscan 200, the modules can annunciate the status of initiating and notification circuits, relays, and several system control functions. Up to 32 devices can be connected to the EIA-485 communications output, all addresses combined. Two way communications can occur with only one annunciator set to address “1”;...

  • Page 44: Providing Power To Annunciators

    Appendix A: Sensiscan 200 Providing Power to Annunciators This communication circuit is supervised by the Sensiscan 200. Loss of communication results in “System Trouble” and “Module Failure” indications at the CPU. Note: “System Trouble” and “Module Failure” will occur if the normally closed supervisory path between Trouble Input Terminals of TB1 on the annunciator is opened (or the jumper has not been installed).

  • Page 45: Program Mapping

    Program Mapping Appendix A: Sensiscan 200 Program Mapping Annunciator points “track” or follow those system points they are programmed to annunciate; they do not latch. The table outlines the annunciation of various system circuits and functions. Note: Control Switches marked “not used” will still function as local LAMP TEST or local ACKNOWLEDGE switches for their respective points.
  • Page 46 Appendix A: Sensiscan 200 Program Mapping NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 47: Appendix B: Sensiscan 2000 Capabilities

    Appendix B: Sensiscan 2000 Capabilities When installed with a Sensiscan 2000, the modules can annunciate the status of initiating and notification circuits, relays, and several system control functions. Each annunciator LED is automatically assigned to one and only one system point. Note: To operate the annunciator module, the CPU must be Revision D or greater.

  • Page 48: Connecting The Eia-485 Circuit

    Appendix B: Sensiscan 2000 Connecting the EIA-485 Circuit Connecting the EIA-485 Circuit Communication between the control panel and the annunciator module is accomplished over a two-wire EIA-485 serial interface. • Power-limited and supervised. • 6000 feet maximum distance (with 16 AWG wire) between the control panel and the furthest annunciator.

  • Page 49: Providing Power To Annunciators

    Providing Power to Annunciators Appendix B: Sensiscan 2000 Providing Power to Annunciators Sensiscan 2000 panels use the MPS-24AF or the MPS-24BF Main Power Supply. This 24 VDC output is filtered, regulated, power-limited, and non- resettable. MPS-24AF - 3 A maximum current draw MPS-24BF - 200 mA maximum current draw The power run to the annunciator does not require a Power Supervision Relay because loss of power is inherently supervised through a communications...

  • Page 50: Installing Modules In The System

    Appendix B: Sensiscan 2000 Installing Modules in the System Installing Modules in the System The annunciator modules begin annunciation with the CPU and continue with the annunciation of circuits on the module installed directly after the CPU. To ensure full employment of annunciator points, mount system modules that require annunciation in the CPU row first, then in the second row, etc.

  • Page 51: Program Mapping

    Program Mapping Appendix B: Sensiscan 2000 Program Mapping Annunciator points “track” or follow those system points they are programmed to annunciate; they do not latch. The table outlines the annunciation of various system circuits and functions. Note: Control Switches marked “not used” will still function as local LAMP TEST or local ACKNOWLEDGE switches for their respective points.
  • Page 52 Appendix B: Sensiscan 2000 Program Mapping NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 53: Appendix C: Ms-9200

    Appendix C: MS-9200 Capabilities The MS-9200 allows annunciators to be programmed by zone or by point. The EIA-485 serial interface will allow up to 32 annunciators, but two-way communications can occur with only one annunciator per address. The other devices must be configured as “Receive Only”. When the panel is programmed by zone, annunciator address 1 is available, and the annunciator modules display the 56 software zones of the MS-9200.

  • Page 54: Providing Power To Annunciators

    Appendix C: MS-9200 Providing Power to Annunciators The EIA-485 circuit is connected between the ACS Mode connector (TB5) on the main circuit board to terminal TB2 on the annunciator (see Figure 5 on page 25). – A CS S HIE L D S LC S LC A + B - A -...

  • Page 55: Program Mapping

    Program Mapping Appendix C: MS-9200 Program Mapping Annunciator points “track” or follow those system points they are programmed to annunciate; they do not latch. The table outlines the annunciation of system functions. Note: Control Switches marked “No Function” will still function as local LAMP TEST or local ACKNOWLEDGE switches for their respective points.
  • Page 56 Appendix C: MS-9200 Program Mapping NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 57: Appendix D: Ms-9600

    Appendix D: MS-9600 Capabilities The MS-9600 allows annunciators to be programmed by zone or by point. The EIA-485 serial interface will allow up to 32 annunciators, but two-way communications can occur with only one annunciator per address. The other devices must be configured as “Receive Only”. When the panel is programmed by zone, annunciator address 1 is available, and the annunciator modules displays the 99 software zones of the MS-9600.

  • Page 58: Providing Power To Annunciators

    Appendix D: MS-9600 Providing Power to Annunciators The EIA-485 circuit is connected between the ACS EIA-485 connector (TB6) on the main circuit board to terminal TB2 on the annunciator (see Figure 5 on page 25). – T B 6 TB6 - ACS EIA-485 connector Figure 26 EIA-485 Circuit Connections - MS-9600 Providing Power to Annunciators...

  • Page 59: Program Mapping

    Program Mapping Appendix D: MS-9600 Program Mapping Annunciator points “track” or follow those system points they are programmed to annunciate; they do not latch. The table outlines the annunciation of system functions. Note: Control Switches marked “No Function” will still function as local LAMP TEST or local ACKNOWLEDGE switches for their respective points.
  • Page 60 Appendix D: MS-9600 Program Mapping NOTES ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...
  • Page 61 Index Index 53, 57 Numerics Control modules 43, 47 Control relays 120 volts AC 20, 38, 39 Control switch 25, 32 120-ohm ELR 120-volt AC 19, 44, 54, 58 current 19, 21, 26, 44, 49 24 VDC 21, 49 current draw 54, 58 24 VDC main power supply custom user labels...
  • Page 62 Index mounting modules MPS-24 Series 19, 23, 43, 48, 53, 57 impedance MPS-24AF 39, 41 Inactive LEDs 44, 49 MPS-24BF 43, 47 Initiating Device Circuits multiple shields Input Voltage 43, 47 Municipal Tie intermediate display 53, 57 NACs 31, 32 National Standard of Canada 31, 32 26, 44, 49, 54, 58...
  • Page 63 Index 25, 26, 29, 30, 31, remote power supply terminal blocks Reset resistance test the system 31, 32 29, 30 ribbon cable threaded tabs 28, 29 Rotory Switches touch-pad switches transmit commands Transmit/Receive 15, 29, 30 trim plate second set 33, 38, 40 trouble condition secondary power supply...
  • Page 64 ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...
  • Page 65 ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...
  • Page 66 ACM-16ATF/ACM-32AF Manual PN 51480:A0 02/02/01...

  • Page 67: Limited Warranty

    Limited Warranty The manufacturer warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date-stamped at time of manufacture. The sole and exclusive obligation of the manufacturer is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service.
  • Page 68 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.firelite.com...
