Owner's Manual & Safety Instructions
Save This Manual
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and
the receipt in a safe and dry place for future reference.
7.5 AMP
RECIPROCATING
SAW
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright
2011 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly, operating,
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE thiS MAnuAl.
ITEM 69067
Advertisement
Table of Contents
Related Manuals for Chicago Electric 69067
Summary of Contents for Chicago Electric 69067
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Table Of Contents
table of Contents Safety ............2 Maintenance ..........12 Specifications ..........8 Parts List and Diagram ......14 Setup ............9 Warranty ............ 16 Operation ............ 9 WARninG SYMBOlS AnD DEFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. -
Page 3: Electrical Safety
Electrical safety 1. Power tool plugs must match the outlet. 4. Do not abuse the cord. never use the cord for never modify the plug in any way. carrying, pulling or unplugging the power tool. Do not use any adapter plugs with grounded Keep cord away from heat, oil, sharp edges power tools. -
Page 4: Reciprocating Saw Safety Warnings
Power tool use and care 1. Do not force the power tool. use the 5. Maintain power tools. Check for misalignment correct power tool for your application. or binding of moving parts, breakage of parts The correct power tool will do the job better and and any other condition that may affect the safer at the rate for which it was designed. -
Page 5: Vibration Safety
Reciprocating Saw Safety Warnings (cont.) 10. WARninG: Some dust created by power sanding, 11. WARninG: handling the cord on this product sawing, grinding, drilling, and other construction will expose you to lead, a chemical known to activities, contains chemicals known [to the the State of California to cause cancer, and birth State of California] to cause cancer, birth defects defects or other reproductive harm. - Page 6 Grounding tO PREVEnt ElECtRiC ShOCK AnD DEAth FROM inCORRECt GROunDinG WiRE COnnECtiOn: Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool. never remove the grounding prong from the plug.
-
Page 7: Extension Cords
Extension Cords 1. Grounded tools require a three wire extension cord. 7. Make sure the extension cord is properly wired Double Insulated tools can use either and in good electrical condition. Always replace a two or three wire extension cord. a damaged extension cord or have it repaired by a qualified electrician before using it. -
Page 8: Specifications
Specifications Electrical Rating 120V~ / 60Hz / 7.5A No Load Speed 0-2500 SPM Stroke Length 1" Setup - Before use: Read the EntiRE iMPORtAnt SAFEtY inFORMAtiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tO PREVEnt SERiOuS injuRY FROM ACCiDEntAl OPERAtiOn: Release the trigger, make sure the trigger lock is not engaged and unplug the tool from its electrical outlet before assembling or making any adjustments to the tool. -
Page 9: Operation
Operating instructions Read the EntiRE iMPORtAnt SAFEtY inFORMAtiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tool Set up Adjusting the Pivot Shoe Hex Key tO PREVEnt SERiOuS injuRY FROM ACCiDEntAl OPERAtiOn: Release the trigger, make sure the trigger lock is not engaged and unplug the tool from its electrical outlet... -
Page 10: Work Piece And Work Area Set Up
Work Piece and Work Area Set up 1. Designate a work area that is clean and well- 3. Secure loose work pieces using a vise or clamps lit. The work area must not allow access by (not included) to prevent movement while working. children or pets to prevent distraction and injury. -
Page 11: General Operating Instructions
General Operating instructions The Saw features a variable speed Trigger. For Plunge Cutting increased strokes per minute, squeeze the Plunge cut into plywood and thin board Trigger harder. For decreased strokes per panels. Do not attempt to plunge cut into minute, apply less pressure to the Trigger. -
Page 12: Maintenance
Maintenance and Servicing Procedures not specifically explained in this manual must be performed only by a qualified technician. tO PREVEnt SERiOuS injuRY FROM ACCiDEntAl OPERAtiOn: Release the trigger, make sure the trigger lock is not engaged and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. -
Page 13: Troubleshooting
troubleshooting Problem Possible Causes likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads. -
Page 14: Parts List And Diagram
Parts list and Diagram PlEASE READ thE FOllOWinG CAREFullY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS qUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS qUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 15: Assembly Diagram
Assembly Diagram 15 16 9 10 11 4 5 6 Item 69067 For technical questions, please call 1-800-444-3353. Page 15... -
Page 16: Warranty
limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
Need help?
Do you have a question about the 69067 and is the answer not in the manual?
Questions and answers
How can I remove the piece left in the saw from a broken off saw blade. It’s in pretty deep
To remove a broken saw blade piece from the Chicago Electric 7.5 Amp Reciprocating Saw model 69067, follow these steps:
1. Unplug the Saw – Disconnect the tool from its power source to prevent accidental operation.
2. Open the Chuck – Rotate the Chuck counterclockwise and hold it in the open position.
3. Remove the Blade Piece – Pull out the broken blade piece carefully.
4. Release the Chuck – Let go of the Chuck to close it.
5. Inspect the Chuck – Ensure no fragments remain inside and that the Chuck functions properly before installing a new blade.
Always wear work gloves to prevent injury while handling broken blades.
