Connecting the OSD Module
All adjustments are made by using the remote on-screen display (OSD) module.
First, connect the OSD module by inserting the corded end into the OSD
module connector in the back of the monitor.
OSD module
3-16
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
AUTO/SEL DOWN UP MENU
Brick power supply
Connections on underside
OSD module cable port
Power
cable
