Frigidaire FRT21G3C Factory Parts Catalog
Top-mount refrigerator r134a series
Hide thumbs
Also See for FRT21G3C:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
N05L00004.eps N05DBDCKA0.eps N05BBAABA6.eps N05SAAADF11.eps
N05CABBAB6.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21G3CQ8 FRT21G3CW5 FRT21G3CW8
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America North America North America
Energy Guide
240572115
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995422317
04/11/17
(EN/SERVICE/WC)
390
R134a
R134a
white
white
115
115
240398801
240398801
240400111
240400112
240572115
240572115
240379014
240379014
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21G3C
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21G3C
Summary of Contents for Frigidaire FRT21G3C
- Page 1 Product No. FRT21G3CQ8 FRT21G3CW5 FRT21G3CW8 Series R134a R134a R134a Color bisque white white Volts Wiring Diagram 240398801 240398801 240398801 Owner's Guide 240400112 240400111 240400112 Market North America North America North America Energy Guide 240572115 240572115 240572115 Service Data Sheet 240379014 240379014 240379014 Installation Instructions 240568300...
- Page 2 Publication No: 5995422317 FRT21G3C DOOR N05DBDCKA0 11/04...
- Page 3 FRT21G3C Publication No: 5995422317 DOOR Model Index: A FRT21G3C (FRT21G3CQ8) B FRT21G3C (FRT21G3CW5) C FRT21G3C (FRT21G3CW8) POS. NO PART NO. DESCRIPTION 240514607 A B C Gasket, seal, white, frzr door, magnetic 240514608 A B C Gasket, seal, white, refr door, magnetic 240534901 A B C Rack-door...
- Page 4 Publication No: 5995422317 FRT21G3C CABINET 11/04...
- Page 5 FRT21G3C Publication No: 5995422317 CABINET Model Index: A FRT21G3C (FRT21G3CQ8) B FRT21G3C (FRT21G3CW5) C FRT21G3C (FRT21G3CW8) POS. NO PART NO. DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut, push-on 241523701 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No: 5995422317 FRT21G3C CABINET 11/04...
- Page 7 FRT21G3C Publication No: 5995422317 CABINET Model Index: A FRT21G3C (FRT21G3CQ8) B FRT21G3C (FRT21G3CW5) C FRT21G3C (FRT21G3CW8) POS. NO PART NO. DESCRIPTION 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin 241574607 A B C Cover-access, w/label 241500301 A B C Screw, hex washer head, 8-18AB x 0.500...
- Page 8 Publication No: 5995422317 FRT21G3C SHELVES N05SAAADF11 11/04...
- Page 9 FRT21G3C Publication No: 5995422317 SHELVES Model Index: A FRT21G3C (FRT21G3CQ8) B FRT21G3C (FRT21G3CW5) C FRT21G3C (FRT21G3CW8) POS. NO PART NO. DESCRIPTION 215667501 A B C Tray, ice cube, plastic 240358003 A B C Shelf, freezer, full-width, wire 5303299664 A B C Spacer, shelf 240545901 A B C...
- Page 10 Publication No: 5995422317 FRT21G3C SYSTEM N05CABBAB6 11/04...
- Page 11 FRT21G3C Publication No: 5995422317 SYSTEM Model Index: A FRT21G3C (FRT21G3CQ8) B FRT21G3C (FRT21G3CW5) C FRT21G3C (FRT21G3CW8) POS. NO PART NO. DESCRIPTION 240444401 A B C Condenser, dynamic 218944001 A B C Drier-filter, R134a System 6* # 240388701 A B C Wiring Harness, control box 6* # 240496101...
-
Page 12: Wiring Schematic
Publication No: 5995422317 FRT21G3C WIRING SCHEMATIC 11/04... -
Page 13: Wiring Diagram
FRT21G3C Publication No: 5995422317 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
