Frigidaire FRT21PRH Factory Parts Catalog
Hide thumbs
Also See for FRT21PRH:
- Factory parts catalog (15 pages) ,
- Factory parts catalog (15 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21PRHB6
FRT21PRH
FRT21PRHD6
FRT21PRH
FRT21PRHW6
FRT21PRH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995335410
000328
-EN/SERVICE/KHB
357
REFRIGERATOR
VOLTS
115
115
115
REFRIGERATOR
Model No.
FRT21PRH
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21PRH
Summary of Contents for Frigidaire FRT21PRH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21PRHB6 FRT21PRH R134a black FRT21PRHD6 FRT21PRH R134a almond FRT21PRHW6 FRT21PRH R134a white MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21PRH 5995335410 DOOR 03/00...
- Page 3 FRT21PRH Publication No. 5995335410 DOOR A = FRT21PRH (FRT21PRHB6) B = FRT21PRH (FRT21PRHD6) C = FRT21PRH (FRT21PRHW6) POS. NO PART NO DESCRIPTION 215608923 A - - Gasket-frzr door,black ,magnetic 215608913 - B C Gasket-frzr door,white ,magnetic 218730622 A - - Gasket-refr door,black ,magnetic 218730609 - B C...
- Page 4 Publication No. FRT21PRH 5995335410 CABINET 03/00...
- Page 5 FRT21PRH Publication No. 5995335410 CABINET A = FRT21PRH (FRT21PRHB6) B = FRT21PRH (FRT21PRHD6) C = FRT21PRH (FRT21PRHW6) POS. NO PART NO DESCRIPTION 5304402655 A B C Cover-fan 5303307351 A B C Knob-damper control 5303001028 A B C Nut,push-on 218722200 A B C Damper-fan cover,black 218649000 A B C...
- Page 6 Publication No. FRT21PRH 5995335410 CABINET 03/00...
- Page 7 FRT21PRH Publication No. 5995335410 CABINET A = FRT21PRH (FRT21PRHB6) B = FRT21PRH (FRT21PRHD6) C = FRT21PRH (FRT21PRHW6) POS. NO PART NO DESCRIPTION 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875 215099718 A - - Plug-button,black 215099711 - B - Plug-button,almond 215099701 - - C...
- Page 8 Publication No. FRT21PRH 5995335410 SHELVES 03/00...
- Page 9 FRT21PRH Publication No. 5995335410 SHELVES A = FRT21PRH (FRT21PRHB6) B = FRT21PRH (FRT21PRHD6) C = FRT21PRH (FRT21PRHW6) POS. NO PART NO DESCRIPTION 218651902 A - - Mullion,black 218651901 - B - Mullion,almond 218651900 - - C Mullion,white 218781002 A B C Heater-mullion 218845602 A B C...
- Page 10 Publication No. FRT21PRH 5995335410 SYSTEM 03/00...
- Page 11 FRT21PRH Publication No. 5995335410 SYSTEM A = FRT21PRH (FRT21PRHB6) B = FRT21PRH (FRT21PRHD6) C = FRT21PRH (FRT21PRHW6) POS. NO PART NO DESCRIPTION 218657100 A B C Condenser 5304406039 A B C Spacer-tube,5/8 OD x 3" lg 5304406040 A B C Spacer-tube,5/8 OD x 12"...
-
Page 12: Wiring Schematic
Publication No. FRT21PRH 5995335410 WIRING SCHEMATIC 03/00... -
Page 13: Wiring Diagram
FRT21PRH Publication No. 5995335410 WIRING DIAGRAM W193832 # = Fast-moving Parts 03/00 * = Non-Illustrated Parts...
