Frigidaire FRT21PRH Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21PRH
  6. Factory parts catalog
Frigidaire FRT21PRH Factory Parts Catalog

Frigidaire FRT21PRH Factory Parts Catalog

Hide thumbs Also See for FRT21PRH:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21PRHB3
FRT21PRH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
Publication No.
5995329777
991109
-EN/SERVICE/KB
357
REFRIGERATOR
VOLTS
115
REFRIGERATOR
Model No.
FRT21PRH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21PRH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21PRH

Summary of Contents for Frigidaire FRT21PRH

  • Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21PRHB3 FRT21PRH R134a black MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No. FRT21PRH 101 MASTERS BLVD. ANDERSON, SC 29624 Publication No.
