Frigidaire FRT21FS5A Factory Parts Catalog
Top mount refrigerator r134a
Hide thumbs
Also See for FRT21FS5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21FS5AQ4
FRT21FS5A
FRT21FS5AQ5
FRT21FS5A
FRT21FS5AW4
FRT21FS5A
FRT21FS5AW5
FRT21FS5A
MARKET
North America
WIRING DIAGRAM - 240379009
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995373536
020604
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21FS5A
©2002 Electrolux home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21FS5A
Summary of Contents for Frigidaire FRT21FS5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21FS5AQ4 FRT21FS5A R134a bisque FRT21FS5AQ5 FRT21FS5A R134a bisque FRT21FS5AW4 FRT21FS5A R134a white FRT21FS5AW5 FRT21FS5A R134a white MARKET North America WIRING DIAGRAM - 240379009 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - 240379009 TOP MOUNT REFRIGERATOR Model No.
- Page 2 Publication No. FRT21FS5A 5995373536 DOOR 06/02...
- Page 3 FRT21FS5A Publication No. 5995373536 DOOR A = FRT21FS5A (FRT21FS5AQ4) B = FRT21FS5A (FRT21FS5AQ5) C = FRT21FS5A (FRT21FS5AW4) D = FRT21FS5A (FRT21FS5AW5) POS. NO PART NO DESCRIPTION 240514607 A B C D Gasket,frzr door seal ,white ,magnetic 240514608 A B C D Gasket,refr door seal ,white ,magnetic 240337703 A B C D...
- Page 4 Publication No. FRT21FS5A 5995373536 CABINET 06/02...
- Page 5 FRT21FS5A Publication No. 5995373536 CABINET A = FRT21FS5A (FRT21FS5AQ4) B = FRT21FS5A (FRT21FS5AQ5) C = FRT21FS5A (FRT21FS5AW4) D = FRT21FS5A (FRT21FS5AW5) POS. NO PART NO DESCRIPTION 240355402 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT21FS5A 5995373536 SHELVES 06/02...
- Page 7 FRT21FS5A Publication No. 5995373536 SHELVES A = FRT21FS5A (FRT21FS5AQ4) B = FRT21FS5A (FRT21FS5AQ5) C = FRT21FS5A (FRT21FS5AW4) D = FRT21FS5A (FRT21FS5AW5) POS. NO PART NO DESCRIPTION 240358003 A B C D Shelf,freezer ,full-width ,wire 5303299664 A B C D Spacer,shelf 240380202 A B C D Diffuser,air ,top...
- Page 8 Publication No. FRT21FS5A 5995373536 SYSTEM 06/02...
- Page 9 FRT21FS5A Publication No. 5995373536 SYSTEM A = FRT21FS5A (FRT21FS5AQ4) B = FRT21FS5A (FRT21FS5AQ5) C = FRT21FS5A (FRT21FS5AW4) D = FRT21FS5A (FRT21FS5AW5) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240496101 A B C D Wiring Harness, machine compt, w/electric cord 6* #...
-
Page 10: Ice Maker
Publication No. FRT21FS5A 5995373536 ICE MAKER 06/02... - Page 11 FRT21FS5A Publication No. 5995373536 ICE MAKER A = FRT21FS5A (FRT21FS5AQ4) B = FRT21FS5A (FRT21FS5AQ5) C = FRT21FS5A (FRT21FS5AW4) D = FRT21FS5A (FRT21FS5AW5) POS. NO PART NO DESCRIPTION 218976901 A B C D Tube-water inlet, inlet valve to ice maker 5304420650 A B C D Spring,shut-off arm 5308000039...
-
Page 12: Wiring Schematic
Publication No. FRT21FS5A 5995373536 WIRING SCHEMATIC 06/02... -
Page 13: Wiring Diagram
FRT21FS5A Publication No. 5995373536 WIRING DIAGRAM # = Fast-moving Parts 06/02 * = Non-Illustrated Parts...
