Frigidaire FRT21FD3A Factory Parts Catalog
Top mount r134a series
Hide thumbs
Also See for FRT21FD3A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21FD3AQ3
FRT21FD3A
FRT21FD3AQ4
FRT21FD3A
FRT21FD3AT4
FRT21FD3A
FRT21FD3AW3
FRT21FD3A
FRT21FD3AW4
FRT21FD3A
FRT21FD3AZ4
FRT21KD3A
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (right)
R134a
bisque (right)
R134a
bisque (left)
R134a
white (right)
R134a
white (right)
R134a
white (left)
Publication No.
5995372363
020517
-EN/SERVICE /KC
365
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21FD3A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21FD3A
Summary of Contents for Frigidaire FRT21FD3A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21FD3AQ3 FRT21FD3A R134a bisque (right) FRT21FD3AQ4 FRT21FD3A R134a bisque (right) FRT21FD3AT4 FRT21FD3A R134a bisque (left) FRT21FD3AW3 FRT21FD3A R134a white (right) FRT21FD3AW4 FRT21FD3A R134a white (right) FRT21FD3AZ4 FRT21KD3A R134a white (left) MARKET North America WIRING DIAGRAM - # 240379009...
- Page 2 Publication No. FRT21FD3A 5995372363 DOOR 05/02...
- Page 3 FRT21FD3A Publication No. 5995372363 DOOR A = FRT21FD3A (FRT21FD3AQ3) B = FRT21FD3A (FRT21FD3AQ4) C = FRT21FD3A (FRT21FD3AT4) D = FRT21FD3A (FRT21FD3AW3) E = FRT21FD3A (FRT21FD3AW4) F = FRT21FD3A (FRT21FD3AZ4) POS. NO PART NO DESCRIPTION 240514607 A B C D E F Gasket,frzr door seal ,white ,magnetic 240514608 A B C D E F...
- Page 4 Publication No. FRT21FD3A 5995372363 CABINET 05/02...
- Page 5 FRT21FD3A Publication No. 5995372363 CABINET A = FRT21FD3A (FRT21FD3AQ3) B = FRT21FD3A (FRT21FD3AQ4) C = FRT21FD3A (FRT21FD3AT4) D = FRT21FD3A (FRT21FD3AW3) E = FRT21FD3A (FRT21FD3AW4) F = FRT21FD3A (FRT21FD3AZ4) POS. NO PART NO DESCRIPTION 240355402 A B C D E F Cover-fan 240433201 A B C D E F...
- Page 6 Publication No. FRT21FD3A 5995372363 SHELVES 05/02...
- Page 7 FRT21FD3A Publication No. 5995372363 SHELVES A = FRT21FD3A (FRT21FD3AQ3) B = FRT21FD3A (FRT21FD3AQ4) C = FRT21FD3A (FRT21FD3AT4) D = FRT21FD3A (FRT21FD3AW3) E = FRT21FD3A (FRT21FD3AW4) F = FRT21FD3A (FRT21FD3AZ4) POS. NO PART NO DESCRIPTION 240358003 A B C D E F Shelf,freezer ,full-width ,wire 5303299664 A B C D E F...
- Page 8 Publication No. FRT21FD3A 5995372363 SYSTEM 05/02...
- Page 9 FRT21FD3A Publication No. 5995372363 SYSTEM A = FRT21FD3A (FRT21FD3AQ3) B = FRT21FD3A (FRT21FD3AQ4) C = FRT21FD3A (FRT21FD3AT4) D = FRT21FD3A (FRT21FD3AW3) E = FRT21FD3A (FRT21FD3AW4) F = FRT21FD3A (FRT21FD3AZ4) POS. NO PART NO DESCRIPTION 240444401 A B C D E F Condenser,dynamic 218944001 A B C D E F...
-
Page 10: Ice Maker
Publication No. FRT21FD3A 5995372363 ICE MAKER 05/02... - Page 11 FRT21FD3A Publication No. 5995372363 ICE MAKER A = FRT21FD3A (FRT21FD3AQ3) B = FRT21FD3A (FRT21FD3AQ4) C = FRT21FD3A (FRT21FD3AT4) D = FRT21FD3A (FRT21FD3AW3) E = FRT21FD3A (FRT21FD3AW4) F = FRT21FD3A (FRT21FD3AZ4) POS. NO PART NO DESCRIPTION 218976901 A B C D E F Tube-water inlet,inlet valve ,to ice maker 5304420650 A B C D E F...
-
Page 12: Wiring Schematic
Publication No. FRT21FD3A 5995372363 WIRING SCHEMATIC 05/02... -
Page 13: Wiring Diagram
FRT21FD3A Publication No. 5995372363 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
