Frigidaire FRT21FR6A Factory Parts Catalog
Top mount r134a series
Hide thumbs
Also See for FRT21FR6A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21FR6AB2
FRT21FR6A
FRT21FR6AB3
FRT21FR6A
FRT21FR6AQ2
FRT21FR6A
FRT21FR6AQ3
FRT21FR6A
FRT21FR6AW2
FRT21FR6A
FRT21FR6AW3
FRT21FR6A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995364725
020128
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21FR6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21FR6A
Summary of Contents for Frigidaire FRT21FR6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21FR6AB2 FRT21FR6A R134a black FRT21FR6AB3 FRT21FR6A R134a black FRT21FR6AQ2 FRT21FR6A R134a bisque FRT21FR6AQ3 FRT21FR6A R134a bisque FRT21FR6AW2 FRT21FR6A R134a white FRT21FR6AW3 FRT21FR6A R134a white MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 TOP MOUNT SERVICE DATA SHEET - # 240379007...
- Page 2 Publication No. FRT21FR6A 5995364725 DOOR 01/02...
- Page 3 FRT21FR6A Publication No. 5995364725 DOOR A = FRT21FR6A (FRT21FR6AB2) B = FRT21FR6A (FRT21FR6AB3) C = FRT21FR6A (FRT21FR6AQ2) D = FRT21FR6A (FRT21FR6AQ3) E = FRT21FR6A (FRT21FR6AW2) F = FRT21FR6A (FRT21FR6AW3) POS. NO PART NO DESCRIPTION 240514611 A B - - - - Gasket-frzr door,black ,magnetic 240514607 - - C D E F...
- Page 4 Publication No. FRT21FR6A 5995364725 CABINET 01/02...
- Page 5 FRT21FR6A Publication No. 5995364725 CABINET A = FRT21FR6A (FRT21FR6AB2) B = FRT21FR6A (FRT21FR6AB3) C = FRT21FR6A (FRT21FR6AQ2) D = FRT21FR6A (FRT21FR6AQ3) E = FRT21FR6A (FRT21FR6AW2) F = FRT21FR6A (FRT21FR6AW3) POS. NO PART NO DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F...
- Page 6 Publication No. FRT21FR6A 5995364725 SHELVES 01/02...
- Page 7 FRT21FR6A Publication No. 5995364725 SHELVES A = FRT21FR6A (FRT21FR6AB2) B = FRT21FR6A (FRT21FR6AB3) C = FRT21FR6A (FRT21FR6AQ2) D = FRT21FR6A (FRT21FR6AQ3) E = FRT21FR6A (FRT21FR6AW2) F = FRT21FR6A (FRT21FR6AW3) POS. NO PART NO DESCRIPTION 240358003 A B C D E F Shelf-freezer 5303299664 A B C D E F...
- Page 8 Publication No. FRT21FR6A 5995364725 SYSTEM 01/02...
- Page 9 FRT21FR6A Publication No. 5995364725 SYSTEM A = FRT21FR6A (FRT21FR6AB2) B = FRT21FR6A (FRT21FR6AB3) C = FRT21FR6A (FRT21FR6AQ2) D = FRT21FR6A (FRT21FR6AQ3) E = FRT21FR6A (FRT21FR6AW2) F = FRT21FR6A (FRT21FR6AW3) POS. NO PART NO DESCRIPTION 240444401 A B C D E F Condenser,dynamic 218944001 A B C D E F...
-
Page 10: Ice Maker
Publication No. FRT21FR6A 5995364725 ICE MAKER 01/02... - Page 11 FRT21FR6A Publication No. 5995364725 ICE MAKER A = FRT21FR6A (FRT21FR6AB2) B = FRT21FR6A (FRT21FR6AB3) C = FRT21FR6A (FRT21FR6AQ2) D = FRT21FR6A (FRT21FR6AQ3) E = FRT21FR6A (FRT21FR6AW2) F = FRT21FR6A (FRT21FR6AW3) POS. NO PART NO DESCRIPTION 218976901 A B C D E F Tube-water inlet, inlet valve to ice maker 5304420650 A B C D E F...
-
Page 12: Wiring Schematic
Publication No. FRT21FR6A 5995364725 WIRING SCHEMATIC 01/02... -
Page 13: Wiring Diagram
FRT21FR6A Publication No. 5995364725 WIRING DIAGRAM # = Fast-moving Parts 01/02 * = Non-Illustrated Parts...
