Factory Parts Catalog
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00006.eps N05DAACKA1.eps N05BBAAAD0.eps N05SACAFE11.eps
N05CABBAB6.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21FS6DK0 FRT21FS6DQ0 FRT21FS6DS0 FRT21FS6DW0
R134a
R134a
stainless lh
bisque
115
115
240398801
240398801
240400111
240400111
North America North America North America North America
241585906
241585906
240379014
240379014
240568300
240398801.eps 240398601.eps
Publication No.
5995412680
04/07/06
(EN/SERVICE/WC)
390
R134a
R134a
stainless
white
115
115
240398801
240398801
240400111
240400111
241585906
241585906
240379014
240379014
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21FS6D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21FS6D
Summary of Contents for Frigidaire FRT21FS6D
- Page 1 North America North America North America North America 241585906 241585906 241585906 240379014 240379014 240379014 240568300 240568300 TOP-MOUNT REFRIGERATOR WITH ICE-MAKER Model No. FRT21FS6D Publication No. 5995412680 04/07/06 (EN/SERVICE/WC) © Copyright 2004 Electrolux Home Products, Inc. R134a white 240398801 240400111 241585906...
- Page 2 Publication No: 5995412680 07/04 FRT21FS6D DOOR N05DAACKA1...
- Page 3 215870633 215870629 218676004 218490901 # Functional Parts * Non-Illustrated Parts FRT21FS6D DOOR A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION A - C - Gasket, seal, black, frzr door, magnetic - B - D Gasket, seal, white, frzr door, magnetic...
- Page 4 Publication No: 5995412680 07/04 FRT21FS6D CABINET N05BBAAAD0...
- Page 5 218362500 240516501 5303001343 240442703 240442704 # Functional Parts * Non-Illustrated Parts FRT21FS6D CABINET A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION A B C D Cover-fan A B C D Knob-damper control A B C D...
- Page 6 Publication No: 5995412680 07/04 FRT21FS6D CABINET N05BBAAAD0...
- Page 7 216850900 218990901 5303305345 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT21FS6D CABINET A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION - - - D Screw-#10-32 X 3/4, white A - C - Grille/Kickplate, black...
- Page 8 Publication No: 5995412680 07/04 FRT21FS6D SHELVES N05SACAFE11...
- Page 9 240443318 240357802 240350654 5308016566 215005100 # Functional Parts * Non-Illustrated Parts FRT21FS6D SHELVES A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION A B C D Shelf, freezer, full-width, wire A B C D Diffuser-air, top...
- Page 10 Publication No: 5995412680 FRT21FS6D SYSTEM N05CABBAB6 07/04...
- Page 11 240493101 240409302 240396801 5303918210 5304421289 # Functional Parts * Non-Illustrated Parts FRT21FS6D SYSTEM A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION A B C D Condenser, dynamic A B C D Drier-filter, R134a System A B C D...
-
Page 12: Ice Maker
Publication No: 5995412680 FRT21FS6D ICE MAKER 07/04... - Page 13 5303001549 218888001 240352403 # Functional Parts * Non-Illustrated Parts FRT21FS6D ICE MAKER A FRT21FS6D (FRT21FS6DK0) B FRT21FS6D (FRT21FS6DQ0) C FRT21FS6D (FRT21FS6DS0) D FRT21FS6D (FRT21FS6DW0) DESCRIPTION A B C D Tube-water inlet, inlet valve, to ice maker A B C D...
-
Page 14: Wiring Schematic
Publication No: 5995412680 FRT21FS6D WIRING SCHEMATIC 07/04... -
Page 15: Wiring Diagram
FRT21FS6D Publication No: 5995412680 WIRING DIAGRAM 07/04 # Functional Parts * Non-Illustrated Parts...
