Frigidaire FRT21FS6D Factory Parts Catalog

Frigidaire FRT21FS6D Factory Parts Catalog

Top-mount refrigerator with ice-maker r134a series
Hide thumbs Also See for FRT21FS6D:

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00006.eps N05DAACKA1.eps N05BBAAAD0.eps N05SACAFE11.eps
N05CABBAB10.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
FRT21FS6DQ1 FRT21FS6DQ2 FRT21FS6DW1 FRT21FS6DW2 FRT21FS6DW3
R134a
R134a
bisque
bisque
115
115
240398801
240398801
240400111
240400112
North America North America North America
241585906
241585906
240379014
240379014
240568300
240398801.eps 240398601.eps
Publication No.
5995431680
05/03/16
(EN/SERVICE/WC)
390
R134a
R134a
R134a
white
white
white
115
115
115
240398801
240398801
240398801
240400111
240400112
240400112
North America
North America
241585906
241585906
241585906
240379014
240379014
241643300
240568300
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21FS6D
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21FS6D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21FS6D

Summary of Contents for Frigidaire FRT21FS6D

  • Page 1 Product No. FRT21FS6DQ1 FRT21FS6DQ2 FRT21FS6DW1 FRT21FS6DW2 FRT21FS6DW3 Series R134a R134a R134a R134a R134a Color bisque bisque white white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400112 240400111 240400112 240400112 Market North America North America North America North America North America Energy Guide...
  • Page 2 Publication No: 5995431680 FRT21FS6D DOOR N05DAACKA1 03/05...
  • Page 3 FRT21FS6D Publication No: 5995431680 DOOR Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 240514607 A B C D E Gasket, seal, white, frzr door, magnetic 240514608 A B C D E Gasket, seal, white, refr door, magnetic 240534901...
  • Page 4 Publication No: 5995431680 FRT21FS6D CABINET N05BBAAAD0 03/05...
  • Page 5 FRT21FS6D Publication No: 5995431680 CABINET Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 240355402 A B C D E Cover-fan 240367001 A B C D E Knob-damper control 5303001028 A B C D E...
  • Page 6 Publication No: 5995431680 FRT21FS6D CABINET N05BBAAAD0 03/05...
  • Page 7 FRT21FS6D Publication No: 5995431680 CABINET Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 5304418225 A B C D E Roller, compressor base, rear, (2) 5303316859 A B C D E Rivet, flat head, 1/4 OD x 1-3/4, roller pin 241574607 A B C D E...
  • Page 8 Publication No: 5995431680 FRT21FS6D SHELVES N05SACAFE11 03/05...
  • Page 9 FRT21FS6D Publication No: 5995431680 SHELVES Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 240358003 A B C D E Shelf, freezer, full-width, wire 5303299664 A B C D E Spacer, shelf 240545901 A B C D E...
  • Page 10 Publication No: 5995431680 FRT21FS6D SYSTEM N05CABBAB10 03/05...
  • Page 11 FRT21FS6D Publication No: 5995431680 SYSTEM Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 240444401 A B C D E Condenser, dynamic 218944001 A B C D E Drier-filter, R134a System 240496101 A - C - -...

  • Page 12: Ice Maker

    Publication No: 5995431680 FRT21FS6D ICE MAKER 03/05...
  • Page 13 FRT21FS6D Publication No: 5995431680 ICE MAKER Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 218976901 A B C D E Tube-water inlet, inlet valve, to ice maker 240561701 A B C D E Seal-water inlet, inlet valve, to ice maker...
  • Page 14 Publication No: 5995431680 FRT21FS6D ICE MAKER 03/05...
  • Page 15 FRT21FS6D Publication No: 5995431680 ICE MAKER Model Index: A FRT21FS6D (FRT21FS6DQ1) B FRT21FS6DQ (FRT21FS6DQ2) C FRT21FS6D (FRT21FS6DW1) D FRT21FS6D (FRT21FS6DW2) E FRT21FS6D (FRT21FS6DW3) POS. NO PART NO. DESCRIPTION 5303001343 A B C D E Screw, hex washer head, 8-15A x 0.500 218721500 A B C D E Bracket-leveling, ICE MAKER...

  • Page 16: Wiring Schematic

    Publication No: 5995431680 FRT21FS6D WIRING SCHEMATIC 03/05...

  • Page 17: Wiring Diagram

    FRT21FS6D Publication No: 5995431680 WIRING DIAGRAM 03/05 # Functional Parts * Non-Illustrated Parts...
