PRODUCT NO.
BASE MODEL NO.
FRT18QGJD0
FRT18QGJ
FRT18QGJW0
FRT18QGJ
FRT18IQGJD0
FRT18IQGJ
FRT18IQGJW0
FRT18IQGJ
MARKET
North America
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
R134a System
almond
R134a System
white
Publication No.
5995332441
000131
-EN/SERVICE /ECL
390
REFRIGERATOR
VOLTS
115
115
115
115
REFRIGERATOR
Model No.
FRT18QGJ
FRT18IQGJ
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18QGJ
Summary of Contents for Frigidaire FRT18QGJ
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18QGJD0 FRT18QGJ R134a System almond FRT18QGJW0 FRT18QGJ R134a System white FRT18IQGJD0 FRT18IQGJ R134a System almond FRT18IQGJW0 FRT18IQGJ R134a System white MARKET North America WIRING DIAGRAM - #193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218758400 REFRIGERATOR Model No.
- Page 2 Publication No. FRT18QGJ, FRT18IQGJ 5995332441 DOOR 01/00...
- Page 3 FRT18QGJ, FRT18IQGJ Publication No. 5995332441 DOOR A = FRT18QGJ (FRT18QGJD0) B = FRT18QGJ (FRT18QGJW0) C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 215608916 A B C D Gasket-frzr door,white ,magnetic 218730605 A B C D Gasket-refr door,white ,magnetic 218360701 A B C D...
- Page 4 Publication No. FRT18QGJ, FRT18IQGJ 5995332441 CABINET 01/00...
- Page 5 FRT18QGJ, FRT18IQGJ Publication No. 5995332441 CABINET A = FRT18QGJ (FRT18QGJD0) B = FRT18QGJ (FRT18QGJW0) C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 218672501 A B C D Cover-fan 5303307351 A B C D Knob-damper control 5303001028 A B C D Nut,push-on...
- Page 6 Publication No. FRT18QGJ, FRT18IQGJ 5995332441 CABINET 01/00...
- Page 7 FRT18QGJ, FRT18IQGJ Publication No. 5995332441 CABINET A = FRT18QGJ (FRT18QGJD0) B = FRT18QGJ (FRT18QGJW0) C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 218915402 A - C - Grille/Kickplate,almond ,w/fasteners 218915401 - B - D Grille/Kickplate,white ,w/fasteners 218896804 A B C D •...
- Page 8 Publication No. FRT18QGJ, FRT18IQGJ 5995332441 SHELVES 01/00...
- Page 9 FRT18QGJ, FRT18IQGJ Publication No. 5995332441 SHELVES A = FRT18QGJ (FRT18QGJD0) B = FRT18QGJ (FRT18QGJW0) C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 218874311 A - C - Mullion,almond 218874301 - B - D Mullion,white 218781003 A B C D Heater-mullion 218845602...
- Page 10 Publication No. FRT18QGJ, FRT18IQGJ 5995332441 SYSTEM 01/00...
- Page 11 FRT18QGJ, FRT18IQGJ Publication No. 5995332441 SYSTEM A = FRT18QGJ (FRT18QGJD0) B = FRT18QGJ (FRT18QGJW0) C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 218173900 A B C D Condenser 5303208866 A B C D Spacer-cond tube,black 5308000296 A B C D Bracket,condenser mtg ,(4)
-
Page 12: Ice Maker
Publication No. FRT18IQGJ 5995332441 ICE MAKER 01/00... - Page 13 FRT18IQGJ Publication No. 5995332441 ICE MAKER C = FRT18IQGJ (FRT18IQGJD0) D = FRT18IQGJ (FRT18IQGJW0) POS. NO PART NO DESCRIPTION 5303015131 - - C D Tube-water,71" ,valve-to-IM 3206348 - - C D Spring,shut-off arm 3206299 - - C D Label,ID plate 3206301 - - C D Gear...
-
Page 14: Wiring Schematic
Publication No. FRT18QGJ, FRT18IQGJ 5995332441 WIRING SCHEMATIC 01/00... -
Page 15: Wiring Diagram
FRT18QGJ, FRT18IQGJ Publication No. 5995332441 WIRING DIAGRAM # = Fast-moving Parts 01/00 * = Non-Illustrated Parts...
