ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
240398801.eps 240398601.eps
Publication No.
5995429775
05/02/23
(EN/SERVICE/)
390
FRT18IS6CB3
R134a
black
115
240398801
240400112
North America
240572138
240379014
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IS6CB
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18IS6CB
Summary of Contents for Frigidaire FRT18IS6CB
- Page 1 Product No. FRT18IS6CB3 Series R134a Color black Volts Wiring Diagram 240398801 Owner's Guide 240400112 Market North America Energy Guide 240572138 Service Data Sheet 240379014 Installation Instructions 240568300 TOP-MOUNT N05L00002.eps N05DCDBCA1.eps N05BBAAAA9.eps N05SACAFI13.eps REFRIGERATOR WITH N05CABBAB6.eps 115-1.eps 240398801.eps 240398601.eps ICE-MAKER ELECTROLUX HOME PRODUCTS, INC. Model No.
- Page 2 Publication No: 5995429775 FRT18IS6CB3 DOOR N05DCDBCA1 02/05...
- Page 3 FRT18IS6CB3 Publication No: 5995429775 DOOR POS. NO PART NO. DESCRIPTION 240514609 Gasket, frzr door seal, black, magnetic 240514612 Gasket, seal, black, refr door, magnetic 240337703 Door-dairy, w/o graphics, clear 240381303 Plug-button, black, hinge brg hole 240476203 Panel-frzr door, black, complete assy 240416304 Nameplate, black 240312405...
- Page 4 Publication No: 5995429775 FRT18IS6CB3 CABINET N05BBAAAA9 02/05...
- Page 5 FRT18IS6CB3 Publication No: 5995429775 CABINET POS. NO PART NO. DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 240367401 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240462010 Cover-evap coil 240568605 Seal-coil cover 10*# 240524701 Wiring Harness, freezer section...
- Page 6 Publication No: 5995429775 FRT18IS6CB3 SHELVES 02/05...
- Page 7 FRT18IS6CB3 Publication No: 5995429775 SHELVES POS. NO PART NO. DESCRIPTION 240358002 Shelf-freezer, full width 5303299664 Spacer, shelf 240545001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 241555401 Light Bulb 241559801 Socket-light 240352701 Control Box 17*# 240388701 Wiring Harness, control box 240360801 Knob, temp control 21 #...
- Page 8 Publication No: 5995429775 FRT18IS6CB3 SYSTEM N05CABBAB6 02/05...
- Page 9 FRT18IS6CB3 Publication No: 5995429775 SYSTEM POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 240581701 Harness-wiring, machine compt 6* # 240388701 Wiring Harness, control box 6* # 240524701 Wiring Harness, freezer section 6* # 240581801 Harness-wiring, compressor 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Ice Maker
Publication No: 5995429775 FRT18IS6CB3 ICE MAKER 02/05... - Page 11 FRT18IS6CB3 Publication No: 5995429775 ICE MAKER POS. NO PART NO. DESCRIPTION 218976901 Tube-water inlet, inlet valve, to ice maker 240561701 Seal-water inlet, inlet valve, to ice maker 5304420650 Spring, shut-off arm 3206299 Label, ID plate 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire, 8-32 x 0.250 3206306 Motor-ice maker...
-
Page 12: Wiring Schematic
Publication No: 5995429775 FRT18IS6CB3 WIRING SCHEMATIC 02/05... -
Page 13: Wiring Diagram
FRT18IS6CB3 Publication No: 5995429775 WIRING DIAGRAM 02/05 # Functional Parts * Non-Illustrated Parts...
