Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568303
N05L00003.eps N05DCDBBA16.eps N05BBAAAA17.eps N05SACAFI17.eps
N05CAABAD4.eps 115-1.eps
P.O. BOX 212378
AUGUSTA, GA 30917
FRT18IL6JB1 FRT18IL6JK1 FRT18IL6JM1 FRT18IL6JS1 FRT18IL6JW1
R134a
R134a
black
stainless (LH) silver mist
115
115
241582401
241582401
241857201
241857201
North America North America North America North America North America
241868097
241868097
241588203
241588203
240568303
W241582401.eps S241582801.eps
Publication No.
5995513230
08/05/01
(EN/SERVICE/DCS)
390
R134a
R134a
R134a
stainless (RH) white
115
115
115
241582401
241582401
241582401
241857201
241857201
241857201
241868097
241868097
241868097
241588203
241588203
241588203
240568303
240568303
240568303
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IL6J
©
Copyright
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT18IL6J
Summary of Contents for Frigidaire FRT18IL6J
- Page 1 Product No. FRT18IL6JB1 FRT18IL6JK1 FRT18IL6JM1 FRT18IL6JS1 FRT18IL6JW1 Series R134a R134a R134a R134a R134a Color black stainless (LH) silver mist stainless (RH) white Volts Wiring Diagram 241582401 241582401 241582401 241582401 241582401 Owner's Guide 241857201 241857201 241857201 241857201 241857201 Market North America North America North America North America North America Energy Guide 241868097 241868097...
- Page 2 Publication No: 5995513230 FRT18IL6J DOOR Stainless Handle Use same handle on both doors N05DCDBBA16 05/08...
- Page 3 FRT18IL6J Publication No: 5995513230 DOOR Model Index: A FRT18IL6J (FRT18IL6JB1) B FRT18IL6J (FRT18IL6JK1) C FRT18IL6J (FRT18IL6JM1) D FRT18IL6J (FRT18IL6JS1) E FRT18IL6J (FRT18IL6JW1) POS. NO PART NO. DESCRIPTION 241872509 A B C D - Gasket-frzr door, black, magnetic 241872503 - - - - E Gasket-frzr door, white, magnetic 241872512 A B C D -...
- Page 4 Publication No: 5995513230 FRT18IL6J CABINET N05BBAAAA17 05/08...
- Page 5 FRT18IL6J Publication No: 5995513230 CABINET Model Index: A FRT18IL6J (FRT18IL6JB1) B FRT18IL6J (FRT18IL6JK1) C FRT18IL6J (FRT18IL6JM1) D FRT18IL6J (FRT18IL6JS1) E FRT18IL6J (FRT18IL6JW1) POS. NO PART NO. DESCRIPTION 241652301 A B C D E Cover-fan 240367001 A B C D E Knob-damper control 5303001028 A B C D E...
- Page 6 Publication No: 5995513230 FRT18IL6J SHELVES N05SACAFI17 05/08...
- Page 7 FRT18IL6J Publication No: 5995513230 SHELVES Model Index: A FRT18IL6J (FRT18IL6JB1) B FRT18IL6J (FRT18IL6JK1) C FRT18IL6J (FRT18IL6JM1) D FRT18IL6J (FRT18IL6JS1) E FRT18IL6J (FRT18IL6JW1) POS. NO PART NO. DESCRIPTION 240358005 A B C D E Shelf, freezer, full-width, wire 241542001 A B C D E Diffuser, air, top 240362601 A B C D E...
- Page 8 Publication No: 5995513230 FRT18IL6J SYSTEM 24 25 N05CAABAD4 05/08...
- Page 9 FRT18IL6J Publication No: 5995513230 SYSTEM Model Index: A FRT18IL6J (FRT18IL6JB1) B FRT18IL6J (FRT18IL6JK1) C FRT18IL6J (FRT18IL6JM1) D FRT18IL6J (FRT18IL6JS1) E FRT18IL6J (FRT18IL6JW1) POS. NO PART NO. DESCRIPTION 241785404 A B C D E Condenser, dynamic 218944002 A B C D E Drier-filter, R134a System 241607001 A B C D E...
-
Page 10: Ice Maker
Publication No: 5995513230 FRT18IL6J ICE MAKER 05/08... - Page 11 FRT18IL6J Publication No: 5995513230 ICE MAKER Model Index: A FRT18IL6J (FRT18IL6JB1) B FRT18IL6J (FRT18IL6JK1) C FRT18IL6J (FRT18IL6JM1) D FRT18IL6J (FRT18IL6JS1) E FRT18IL6J (FRT18IL6JW1) POS. NO PART NO. DESCRIPTION 218976915 A B C D E Tube-water inlet, inlet valve, to filter 240561701 A B C D E Seal-water inlet, inlet valve, to ice maker...
-
Page 12: Wiring Schematic
Publication No: 5995513230 FRT18IL6J WIRING SCHEMATIC 05/08... -
Page 13: Wiring Diagram
FRT18IL6J Publication No: 5995513230 WIRING DIAGRAM 05/08 # Functional Parts * Non-Illustrated Parts...
