WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995332813
000207
-EN/SERVICE/KHB
390
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT18ISGH
©2000 White Consolidated Industries, Inc.
All rights reserved
