Frigidaire FRT18IS6C Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18IS6C:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT18IS6CQ0
FRT18IS6C
FRT18IS6CW0
FRT18IS6C
MARKET
North America
ENERGY GUIDE - 240572138
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995391652
030610
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18IS6C
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FRT18IS6C

Summary of Contents for Frigidaire FRT18IS6C

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT18IS6CQ0 FRT18IS6C FRT18IS6CW0 FRT18IS6C MARKET North America ENERGY GUIDE - 240572138 OWNER’S GUIDE - 240400109 SERVICE DATA SHEET - # 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a bisque...
  • Page 2 Publication No. FRT18IS6C 5995391652 DOOR 06/03...
  • Page 3 A = FRT18IS6C (FRT18IS6CQ0) B = FRT18IS6C (FRT18IS6CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18IS6C DOOR PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2)
  • Page 4 Publication No. FRT18IS6C 5995391652 CABINET 06/03...
  • Page 5 A = FRT18IS6C (FRT18IS6CQ0) B = FRT18IS6C (FRT18IS6CW0) POS. NO 10*# # = Fast-moving Parts * = Non-Illustrated Parts FRT18IS6C CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666...
  • Page 6 Publication No. FRT18IS6C 5995391652 SHELVES 06/03...
  • Page 7 A = FRT18IS6C (FRT18IS6CQ0) B = FRT18IS6C (FRT18IS6CW0) POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18IS6C SHELVES PART NO DESCRIPTION 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801...
  • Page 8 Publication No. FRT18IS6C 5995391652 SYSTEM 06/03...
  • Page 9 A = FRT18IS6C (FRT18IS6CQ0) B = FRT18IS6C (FRT18IS6CW0) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18IS6C SYSTEM...

  • Page 10: Ice Maker

    Publication No. FRT18IS6C 5995391652 ICE MAKER 06/03...
  • Page 11 A = FRT18IS6C (FRT18IS6CQ0) B = FRT18IS6C (FRT18IS6CW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18IS6C ICE MAKER PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker...

  • Page 12: Wiring Schematic

    Publication No. FRT18IS6C 5995391652 WIRING SCHEMATIC 06/03...

  • Page 13: Wiring Diagram

    FRT18IS6C Publication No. 5995391652 WIRING DIAGRAM # = Fast-moving Parts 06/03 * = Non-Illustrated Parts...
