Frigidaire FRT18IS6C Factory Parts Catalog

Frigidaire FRT18IS6C Factory Parts Catalog

Top-mount refrigerator with ice-maker
Hide thumbs Also See for FRT18IS6C:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
N05L00003.eps N05DCDBCA1.eps N05BBAABA6.eps N05SACAFI13.eps
N05CABBAB6.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
240398801.eps 240398601.eps
Publication No.
5995414918
04/08/12
(EN/SERVICE/WC)
390
FRT18IS6CW1
R134a
white
115
240398801
240400111
North America
240572138
240379014
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IS6C
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading

Related Manuals for Frigidaire FRT18IS6C

Summary of Contents for Frigidaire FRT18IS6C

  • Page 1 Product No. FRT18IS6CW1 Series R134a Color white Volts Wiring Diagram 240398801 Owner's Guide 240400111 Market North America Energy Guide 240572138 Service Data Sheet 240379014 Installation Instructions 240568300 TOP-MOUNT N05L00003.eps N05DCDBCA1.eps N05BBAABA6.eps N05SACAFI13.eps REFRIGERATOR WITH N05CABBAB6.eps 115-1.eps 240398801.eps 240398601.eps ICE-MAKER ELECTROLUX HOME PRODUCTS, INC. P.O.
  • Page 2 Publication No: 5995414918 FRT18IS6CW1 DOOR 08/04...
  • Page 3 FRT18IS6CW1 Publication No: 5995414918 DOOR POS. NO PART NO. DESCRIPTION 240514605 Gasket, frzr door seal, white, magnetic 240514608 Gasket, seal, white, refr door, magnetic 240337703 Door-dairy, w/o graphics, clear 240381301 Plug-button, white, hinge brg hole, (2) 240476201 Panel-frzr door, white, complete assy 240416301 Label-nameplate, white 240312403...
  • Page 4 Publication No: 5995414918 FRT18IS6CW1 CABINET 08/04...
  • Page 5 FRT18IS6CW1 Publication No: 5995414918 CABINET POS. NO PART NO. DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 240367401 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240462010 Cover-evap coil 240568605 Seal-coil cover 10*# 240524701 Wiring Harness, freezer section...
  • Page 6 Publication No: 5995414918 FRT18IS6CW1 SHELVES 08/04...
  • Page 7 FRT18IS6CW1 Publication No: 5995414918 SHELVES POS. NO PART NO. DESCRIPTION 240358002 Shelf-freezer, full width 5303299664 Spacer, shelf 240545001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 241555401 Light Bulb 241559801 Socket-light 240352701 Control Box 240360801 Knob, temp control 21 # 5304421256 Control, temperature...
  • Page 8 Publication No: 5995414918 FRT18IS6CW1 SYSTEM N05CABBAB6 08/04...
  • Page 9 FRT18IS6CW1 Publication No: 5995414918 SYSTEM POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 240581701 Harness-wiring, machine compt 6* # 240388701 Wiring Harness, control box 6* # 240524701 Wiring Harness, freezer section 14 # 5303918208 Defrost Heater Kit 15 # 5303918274 Evaporator Kit...

  • Page 10: Ice Maker

    Publication No: 5995414918 FRT18IS6CW1 ICE MAKER 08/04...
  • Page 11 FRT18IS6CW1 Publication No: 5995414918 ICE MAKER POS. NO PART NO. DESCRIPTION 218976901 Tube-water inlet, inlet valve, to ice maker 240561701 Seal-water inlet, inlet valve, to ice maker 5304420650 Spring, shut-off arm 3206299 Label, ID plate 3206301 Gear 3206303 Plate-mounting 3206305 Screw-ground wire, 8-32 x 0.250 3206306 Motor-ice maker...

  • Page 12: Wiring Schematic

    Publication No: 5995414918 FRT18IS6CW1 WIRING SCHEMATIC 08/04...

  • Page 13: Wiring Diagram

    FRT18IS6CW1 Publication No: 5995414918 WIRING DIAGRAM 08/04 # Functional Parts * Non-Illustrated Parts...
