N58L00002.eps N58FAAAAB4.eps N58RAAABB4.eps N58BAAAAA0.eps
N58SJCACA21.eps N58TAAAAA6.eps N58CAAAAA5.eps N58XDAAAA1.eps
N58YBAAAA2.eps N58I1151.eps W241526901A.eps S241526901A.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6R3EW8
Series
R134a
Color
white
Volts
115
Wiring Diagram
241526901
Owner's Guide
241695301
Market
North America
Energy Guide
241615411
Service Data Sheet 240389616
Publication No.
5995471371
06/08/01
(EN/SERVICE/KHB)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6R3E
©
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS6R3E
Summary of Contents for Frigidaire FRS6R3E
- Page 1 Product No. FRS6R3EW8 Series R134a Color white Volts Wiring Diagram 241526901 Owner's Guide 241695301 Market North America Energy Guide 241615411 Service Data Sheet 240389616 SIDE-BY-SIDE N58L00002.eps N58FAAAAB4.eps N58RAAABB4.eps N58BAAAAA0.eps REFRIGERATOR N58SJCACA21.eps N58TAAAAA6.eps N58CAAAAA5.eps N58XDAAAA1.eps N58YBAAAA2.eps N58I1151.eps W241526901A.eps S241526901A.eps Model No. North &...
-
Page 2: Freezer Door
Publication No: 5995471371 FRS6R3EW8 FREEZER DOOR 08/06... - Page 3 FRS6R3EW8 Publication No: 5995471371 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241674802 Gasket-frzr door, white, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 241668111 Door-frzr, white, complete assy 240581902 Door Stop, white, frzr 218762701 Handle-door, white 240598402 Screw, 10-32 x 1/2 218781101 Screw, pan head, 8-18 x 0.625 240328202 Bearing-hinge(frz), closer...
-
Page 4: Refrigerator Door
Publication No: 5995471371 FRS6R3EW8 REFRIGERATOR DOOR 08/06... - Page 5 FRS6R3EW8 Publication No: 5995471371 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241674801 Gasket-refr door, white, magnetic 240323001 Bin-door, pseudo, bottom 240326203 Door-dairy 240581901 Door Stop, white, refr 240451902 Door-refr, white, complete assy 218762701 Handle-door, white 240598402 Screw, 10-32 x 1/2 218781101 Screw, pan head, 8-18 x 0.625 240328201...
- Page 6 Publication No: 5995471371 FRS6R3EW8 CABINET 08/06...
- Page 7 FRS6R3EW8 Publication No: 5995471371 CABINET POS. NO PART NO. DESCRIPTION 240435912 Cover-air duct 240475911 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457701 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special...
- Page 8 Publication No: 5995471371 FRS6R3EW8 SHELVES N58SJCACA21 08/06...
- Page 9 FRS6R3EW8 Publication No: 5995471371 SHELVES POS. NO PART NO. DESCRIPTION 241657602 Shelf, flip up, wire 241657502 Shelf, fixed, freezer 241657504 Shelf, fixed, upper, freezer 240373108 Frame-shelf, cantilever 240350702 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240350902 Cover-crisper pan, lower 240351007 Pan-crisper, upper 240349801 Clip-slide, pan-crisper 240351207...
- Page 10 Publication No: 5995471371 FRS6R3EW8 CONTROLS N58TAAAAA6 08/06...
- Page 11 FRS6R3EW8 Publication No: 5995471371 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg, (2) 240369702 Motor-evap fan 241517701 Clip, evap fan motor 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 16 # 241513901 Socket-light...
- Page 12 Publication No: 5995471371 FRS6R3EW8 SYSTEM N58CAAAAA5 08/06...
- Page 13 FRS6R3EW8 Publication No: 5995471371 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 241537802 Harness-wiring, control box 241651601 Harness-wiring 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2) 5303918214...
-
Page 14: Ice And Water Dispenser
Publication No: 5995471371 FRS6R3EW8 ICE & WATER DISPENSER 08/06... - Page 15 FRS6R3EW8 Publication No: 5995471371 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube-water inlet, inlet valve, to ice maker 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 241679001 Cover-module, white 241680505...
-
Page 16: Ice Container
Publication No: 5995471371 FRS6R3EW8 ICE CONTAINER 37A 34 34 33 N58YBAAAA2 08/06... - Page 17 FRS6R3EW8 Publication No: 5995471371 ICE CONTAINER POS. NO PART NO. DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice, bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 241624801 Bar-drive 5304404359 Gate 241555401 Light Bulb 241559801 Socket-light 5304404345 Drive Blade 5304447433 Motor-auger 240352601 Wiring Harness, internal, with plug 5304404332 Cover-motor...
-
Page 18: Ice Maker
Publication No: 5995471371 FRS6R3EW8 ICE MAKER 08/06... - Page 19 FRS6R3EW8 Publication No: 5995471371 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube-water inlet, inlet valve, to ice maker 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ICE MAKER 5304456657...
- Page 20 Publication No: 5995471371 FRS6R3EW8 ICE MAKER 08/06...
- Page 21 FRS6R3EW8 Publication No: 5995471371 ICE MAKER POS. NO PART NO. DESCRIPTION 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 Bracket-leveling, ICE MAKER 5304456687 Screw-IM brkt mtg, special, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 218888001 Adapter-water supply, nut &...
-
Page 22: Wiring Schematic
Publication No: 5995471371 FRS6R3EW8 WIRING SCHEMATIC 08/06... -
Page 23: Wiring Diagram
FRS6R3EW8 Publication No: 5995471371 WIRING DIAGRAM 08/06 # Functional Parts * Non-Illustrated Parts...
