ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Product No.
FRS6R3EW1
Series
R134a
Color
white
Volts
115
Wiring Diagram
241526901
Owner's Guide
240581300
Market
North America
Energy Guide
241615411
Service Data Sheet 240389616
Publication No.
5995430294
05/02/28
(EN/SERVICE/DCS)
357
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6R3E
©
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6R3E and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS6R3E

Summary of Contents for Frigidaire FRS6R3E

  • Page 1 R134a Color white Volts Wiring Diagram 241526901 Owner's Guide 240581300 Market North America Energy Guide 241615411 Service Data Sheet 240389616 SIDE-BY-SIDE REFRIGERATOR Model No. FRS6R3E Publication No. 5995430294 05/02/28 (EN/SERVICE/DCS) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved.

  • Page 2: Freezer Door

    Publication No: 5995430294 FRS6R3EW1 FREEZER DOOR 02/05...
  • Page 3 POS. NO PART NO. 240390602 240334201 240351601 240451802 240537102 218762701 5308016566 218781100 240328202 240328402 215870629 241525101 240352102 240552101 5303918256 # Functional Parts * Non-Illustrated Parts FRS6R3EW1 FREEZER DOOR DESCRIPTION Gasket-frzr door, white, magnetic Bin-door, frzr-upper Bin-door Door-frzr, white, complete assy Door Stop, white, frzr Handle-door, white Screw, hex washer head, 8-15A x 0.625, low profile...

  • Page 4: Refrigerator Door

    Publication No: 5995430294 FRS6R3EW1 REFRIGERATOR DOOR 02/05...
  • Page 5 218781100 240328201 240328401 215870629 240356401 # Functional Parts * Non-Illustrated Parts FRS6R3EW1 REFRIGERATOR DOOR DESCRIPTION Gasket-refr door, white, magnetic Bin-door, pseudo, bottom Door-dairy Door Stop, white, ref Door-refr, white, complete assy Handle-door, white Screw, hex washer head, 8-15A x 0.625, low profile Screw, pan head, 8-18 x 0.625...
  • Page 6 Publication No: 5995430294 FRS6R3EW1 CABINET 02/05...
  • Page 7 POS. NO PART NO. 240435906 240475907 5303208309 240505801 241547901 218252200 240457701 240402701 240335501 240419101 240419102 240337601 240327201 240327005 241550801 241550701 240578901 240335003 241500301 218659500 218781100 240374301 66B* 240518802 240324402 5308016566 5304418225 5303316859 241574602 218249808 240380101 216850900 240423701 100* 240350802 240368701 240396801 240479601 240481601...
  • Page 8 Publication No: 5995430294 02/05 FRS6R3EW1 SHELVES N58SJCACA21...
  • Page 9 POS. NO PART NO. 240338802 240338702 240338704 240373108 240350702 240362101 240350902 240351007 240349801 240351207 240357706 240430706 240430702 240350623 240357806 240350649 240350603 240564401 240343002 240343102 5308016566 240545302 218493100 241630701 241630702 240430501 # Functional Parts * Non-Illustrated Parts FRS6R3EW1 SHELVES DESCRIPTION Shelf-freezer, flip-up Shelf-freezer, fixed wire Shelf-freezer, fixed wire Frame-shelf, cantilever...
  • Page 10 Publication No: 5995430294 02/05 FRS6R3EW1 CONTROLS N58TAAAAA6...
  • Page 11 POS. NO PART NO. 5308000010 215474201 241563601 240369702 241517701 241555401 16 # 241513901 240383301 241537802 240360801 21 # 241586501 5304421067 218660702 23 # 241508001 5303001259 240369501 5308016566 218493100 241600902 137# 240389102 137* 218710300 240434401 138* 218904301 240434301 240545201 241563501 149* 241528303 240394102 240376002...
  • Page 12 Publication No: 5995430294 02/05 FRS6R3EW1 SYSTEM N58CAAAAA5...
  • Page 13 POS. NO PART NO. 240333603 218679607 218944001 241586801 240449601 241537802 14 # 5303918253 15 # 5303918284 5308000110 5303918214 240330008 218252200 218513300 240491501 240332602 29 # 5303918316 30 # 241524605 218973501 240405201 240555001 215174700 5308016566 218909913 240542601 218897002 5304430246 240346701 240359401 60 # 240525402 61 #...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995430294 FRS6R3EW1 ICE & WATER DISPENSER 02/05...
  • Page 15 POS. NO PART NO. 218976409 218976901 218976904 218976907 240561701 5304433188 5304422030 5304426649 240570204 5304421616 240548901 5304421619 5304433185 240323601 5304421825 5304421826 5304421628 5304421624 5304421625 5304421629 5304421620 38A# 5304421617 38A* 5304430839 5304436275 38C* 5304430837 5304421627 5304421829 215296300 5304421830 240363401 5304421622 5304421621 5304421615 218515401 5303918256 # Functional Parts...

  • Page 16: Ice Container

    Publication No: 5995430294 02/05 FRS6R3EW1 ICE CONTAINER 37A 34 34 33 N58YBAAAA1...
  • Page 17 POS. NO PART NO. 5304428402 5304404343 218815300 5304404346 218815400 241624801 5304404359 241555401 241559801 5304404345 18 # 5304440392 18*# 240352601 5304404332 215285100 5304404347 5304404362 215503200 5304404351 5304404349 5304404353 5304404352 5304404348 5304404350 5304404356 5304404365 5304404358 218359200 45 # 5304404333 5304406816 5304406817 5304406818 5304406819 5304404341 5304404342...

  • Page 18: Ice Maker

    Publication No: 5995430294 FRS6R3EW1 ICE MAKER 02/05...
  • Page 19 POS. NO PART NO. 218976409 218976901 218976904 218976907 240561701 5304420650 3206299 3206301 3206303 3206305 3206306 3206312 3206313 3206315 11 # 3206319 12 # 240352601 13 # 3206322 5304420652 15 # 3206324 5304420653 17 # 5303320545 3206328 3206330 5304408581 3206332 3206333 5304408582 3206335 3206336...

  • Page 20: Wiring Schematic

    Publication No: 5995430294 FRS6R3EW1 WIRING SCHEMATIC 02/05...

  • Page 21: Wiring Diagram

    FRS6R3EW1 Publication No: 5995430294 WIRING DIAGRAM 02/05 # Functional Parts * Non-Illustrated Parts...
