Frigidaire FRT18IL6D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18IL6D
  6. Factory parts catalog
Frigidaire FRT18IL6D Factory Parts Catalog

Frigidaire FRT18IL6D Factory Parts Catalog

Top-mount refrigerator with ice-maker
Hide thumbs Also See for FRT18IL6D:

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568301
N05L00003.eps N05DCDBBA8.eps N05BBAAAA9.eps N05SACAFI17.eps
N05CAAAAA21.eps 115-1.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRT18IL6DBL FRT18IL6DKL FRT18IL6DML FRT18IL6DQL FRT18IL6DSL FRT18IL6DWL
R134a
R134a
R134a
black
stainless-LH
silver/mist
115
115
115
240398801
240398801
240398801
241694400
241694400
241694400
North America North America North America North America North America North America
240598682
240598682
240598682
240379018
240379018
240379018
240568301
240568301
240398801.eps 240398601.eps
Publication No.
5995469276
06/06/30
(EN/SERVICE/WC)
390
R134a
R134a
R134a
bisque
stainless-RH
white
115
115
115
240398801
240398801
240398801
241694400
241694400
241694400
240598682
240598682
240598682
240379018
240379018
240379018
240568301
240568301
240568301
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IL6D
©
Copyright
2006 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18IL6D and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18IL6D

Summary of Contents for Frigidaire FRT18IL6D

  • Page 1 Product No. FRT18IL6DBL FRT18IL6DKL FRT18IL6DML FRT18IL6DQL FRT18IL6DSL FRT18IL6DWL Series R134a R134a R134a R134a R134a R134a Color black stainless-LH silver/mist bisque stainless-RH white Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide 241694400 241694400 241694400 241694400 241694400 241694400 Market North America North America North America North America North America North America Energy Guide 240598682...
  • Page 2 Publication No: 5995469276 FRT18IL6D DOOR 21 14B N05DCDBBA8 06/06...
  • Page 3 FRT18IL6D Publication No: 5995469276 DOOR Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 240542121 A B C - E - Gasket-frzr door, black, magnetic 240542115 - - - D - F Gasket-frzr door, white, magnetic...
  • Page 4 Publication No: 5995469276 FRT18IL6D CABINET N05BBAAAA9 06/06...
  • Page 5 FRT18IL6D Publication No: 5995469276 CABINET Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 241652301 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303001028 A B C D E F...
  • Page 6 Publication No: 5995469276 FRT18IL6D CABINET N05BBAAAA9 06/06...
  • Page 7 FRT18IL6D Publication No: 5995469276 CABINET Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 5308016566 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile 5304418225 A B C D E F Roller, compressor base, rear, (2)
  • Page 8 Publication No: 5995469276 FRT18IL6D SHELVES N05SACAFI17 06/06...
  • Page 9 FRT18IL6D Publication No: 5995469276 SHELVES Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 240358005 A B C D E F Shelf, freezer, full-width, wire 241542001 A B C D E F Diffuser, air, top...
  • Page 10 Publication No: 5995469276 FRT18IL6D SYSTEM N05CAAAAA21 06/06...
  • Page 11 FRT18IL6D Publication No: 5995469276 SYSTEM Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 241665701 A B C D E F Condenser, dynamic 218944001 A B C D E F Drier-filter, R134a System 241607001...

  • Page 12: Ice Maker

    Publication No: 5995469276 FRT18IL6D ICE MAKER 06/06...
  • Page 13 FRT18IL6D Publication No: 5995469276 ICE MAKER Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 218976901 A B C D E F Tube-water inlet, inlet valve, to ice maker 240561701 A B C D E F Seal-water inlet, inlet valve, to ice maker...
  • Page 14 Publication No: 5995469276 FRT18IL6D ICE MAKER 06/06...
  • Page 15 FRT18IL6D Publication No: 5995469276 ICE MAKER Model Index: A FRT18IL6D (FRT18IL6DBL) B FRT18IL6D (FRT18IL6DKL) C FRT18IL6D (FRT18IL6DML) D FRT18IL6D (FRT18IL6DQL) E FRT18IL6D (FRT18IL6DSL) F FRT18IL6D (FRT18IL6DWL) POS. NO PART NO. DESCRIPTION 5304455650 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile 5303001193 A B C D E F Clamp, .50 ID, steel, water tube...

  • Page 16: Wiring Schematic

    Publication No: 5995469276 FRT18IL6D WIRING SCHEMATIC 06/06...

  • Page 17: Wiring Diagram

    FRT18IL6D Publication No: 5995469276 WIRING DIAGRAM 06/06 # Functional Parts * Non-Illustrated Parts...
