Frigidaire FRT18IL6D Factory Parts Catalog

Frigidaire FRT18IL6D Factory Parts Catalog

Top-mount refrigerator with ice-maker
Hide thumbs Also See for FRT18IL6D:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00003.eps N05DCDBBA8.eps N05BBAAAA9.eps N05SACAFI13.eps
N05CABBAB9.eps 115.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT18IL6DQ4 FRT18IL6DQ6 FRT18IL6DW4 FRT18IL6DW6
R134a
R134a
bisque
bisque
115
115
240398801
240398801
240400111
240400112
North America North America North America North America
240598682
240598682
240379015
240379015
240568300
240398801.eps 240398601.eps
Publication No.
5995421541
04/11/09
(EN/SERVICE/WC)
390
R134a
R134a
white
white
115
115
240398801
240398801
240400111
240400112
240598682
240598682
240379015
240379015
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IL6D
©
Copyright
2004 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18IL6D and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18IL6D

Summary of Contents for Frigidaire FRT18IL6D

  • Page 1 Product No. FRT18IL6DQ4 FRT18IL6DQ6 FRT18IL6DW4 FRT18IL6DW6 Series R134a R134a R134a R134a Color bisque bisque white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400112 240400111 240400112 Market North America North America North America North America Energy Guide 240598682 240598682 240598682...
  • Page 2 Publication No: 5995421541 FRT18IL6D DOOR 21 14B N05DCDBBA8 11/04...
  • Page 3 FRT18IL6D Publication No: 5995421541 DOOR Model Index: A FRT18IL6D (FRT18IL6DQ4) B FRT18IL6D (FRT18IL6DQ6) C FRT18IL6D (FRT18IL6DW4) D FRT18IL6D (FRT18IL6DW6) POS. NO PART NO. DESCRIPTION 240542103 A B C D Gasket-frzr door, white, magnetic 240542106 A B C D Gasket-refr door, white, magnetic 240338303 A B C D Door, dairy, clear...
  • Page 4 Publication No: 5995421541 FRT18IL6D CABINET N05BBAAAA9 11/04...
  • Page 5 FRT18IL6D Publication No: 5995421541 CABINET Model Index: A FRT18IL6D (FRT18IL6DQ4) B FRT18IL6D (FRT18IL6DQ6) C FRT18IL6D (FRT18IL6DW4) D FRT18IL6D (FRT18IL6DW6) POS. NO PART NO. DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut, push-on 241523701 A B C D...
  • Page 6 Publication No: 5995421541 FRT18IL6D SHELVES 11/04...
  • Page 7 FRT18IL6D Publication No: 5995421541 SHELVES Model Index: A FRT18IL6D (FRT18IL6DQ4) B FRT18IL6D (FRT18IL6DQ6) C FRT18IL6D (FRT18IL6DW4) D FRT18IL6D (FRT18IL6DW6) POS. NO PART NO. DESCRIPTION 240358002 A B C D Shelf-freezer, full width 241542001 A B C D Diffuser, air, top 240362601 A B C D Diffuser, air, bottom...
  • Page 8 Publication No: 5995421541 FRT18IL6D SYSTEM N05CABBAB9 11/04...
  • Page 9 FRT18IL6D Publication No: 5995421541 SYSTEM Model Index: A FRT18IL6D (FRT18IL6DQ4) B FRT18IL6D (FRT18IL6DQ6) C FRT18IL6D (FRT18IL6DW4) D FRT18IL6D (FRT18IL6DW6) POS. NO PART NO. DESCRIPTION 240444401 A B C D Condenser, dynamic 218944001 A B C D Drier-filter, R134a System 240581701 A - C - Harness-wiring, machine compt 6* #...

  • Page 10: Ice Maker

    Publication No: 5995421541 FRT18IL6D ICE MAKER 11/04...
  • Page 11 FRT18IL6D Publication No: 5995421541 ICE MAKER Model Index: A FRT18IL6D (FRT18IL6DQ4) B FRT18IL6D (FRT18IL6DQ6) C FRT18IL6D (FRT18IL6DW4) D FRT18IL6D (FRT18IL6DW6) POS. NO PART NO. DESCRIPTION 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 240561701 A B C D Seal-water inlet, inlet valve, to ice maker 5304420650 A B C D...

  • Page 12: Wiring Schematic

    Publication No: 5995421541 FRT18IL6D WIRING SCHEMATIC 11/04...

  • Page 13: Wiring Diagram

    FRT18IL6D Publication No: 5995421541 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
