Frigidaire FRT18FS5A Factory Parts Catalog
Top-mount refrigerator
Hide thumbs
Also See for FRT18FS5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18FS5AQ4
FRT18FS5A
FRT18FS5AW4
FRT18FS5A
PRODUCT NO.
WIRING DIAG
FRT18FS5AQ4
240398801
FRT18FS5AW4
240398801
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400103
SERVICE DATA SHEET - 240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
MARKET
INSTL INSTR
USA
240379102
USA
240379102
Publication number
5995359980
011017
-EN/SERVICE /DJH
390
FACTORY
PARTS CATALO
VOLTS
115
115
ICE MAKER
IM115
IM115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18FS5A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18FS5A
Summary of Contents for Frigidaire FRT18FS5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18FS5AQ4 FRT18FS5A R134a bisque FRT18FS5AW4 FRT18FS5A R134a white PRODUCT NO. WIRING DIAG MARKET INSTL INSTR ICE MAKER FRT18FS5AQ4 240398801 240379102 IM115 FRT18FS5AW4 240398801 240379102 IM115 WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400103 SERVICE DATA SHEET - 240379007 TOP MOUNT...
- Page 2 Publication No. FRT18FS5A 5995359980 DOOR 10/01...
- Page 3 FRT18FS5A Publication No. 5995359980 DOOR A = FRT18FS5A (FRT18FS5AQ4) B = FRT18FS5A (FRT18FS5AW4) POS. NO PART NO DESCRIPTION 240370905 Gasket-frzr door,white ,magnetic 240370906 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381302 Plug-button,hinge brg hole ,bisque ,(2) 240381301 Plug-button,hinge brg hole ,white ,(2) 240410202 Door-frzr,bisque ,complete assy 240410201...
- Page 4 Publication No. FRT18FS5A 5995359980 CABINET 10/01...
- Page 5 FRT18FS5A Publication No. 5995359980 CABINET A = FRT18FS5A (FRT18FS5AQ4) B = FRT18FS5A (FRT18FS5AW4) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462005 Cover-evap coil 240371302 Seal-coil cover...
- Page 6 Publication No. FRT18FS5A 5995359980 SHELVES 10/01...
- Page 7 FRT18FS5A Publication No. 5995359980 SHELVES A = FRT18FS5A (FRT18FS5AQ4) B = FRT18FS5A (FRT18FS5AW4) POS. NO PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer-shelf 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240392601 Seal-diffuser 14 # 240505801 Switch-light/lamp 240436701 Light Bulb/Lamp,A-15 ,40 W ,120 V ,miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18FS5A 5995359980 SYSTEM 10/01...
- Page 9 FRT18FS5A Publication No. 5995359980 SYSTEM A = FRT18FS5A (FRT18FS5AQ4) B = FRT18FS5A (FRT18FS5AW4) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240375301 Wiring Harness,machine compt ,w/ service cord 6* # 240385401 Wiring Harness,freezer section 6* # 240388701 Wiring Harness,control box 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Ice Maker
Publication No. FRT18FS5A 5995359980 ICE MAKER 10/01... - Page 11 FRT18FS5A Publication No. 5995359980 ICE MAKER A = FRT18FS5A (FRT18FS5AQ4) B = FRT18FS5A (FRT18FS5AW4) POS. NO PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker 5304420650 Spring,shut-off arm 5308000039 Screw,hex washer hd ,8-32CA x 0.500 ,serrated hd 3206299 Label,ID plate 3206301 Gear 3206303...
-
Page 12: Wiring Schematic
Publication No. FRT18FS5A 5995359980 WIRING SCHEMATIC 10/01... -
Page 13: Wiring Diagram
FRT18FS5A Publication No. 5995359980 WIRING DIAGRAM # = Fast-moving Parts 10/01 * = Non-Illustrated Parts...
